Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
QGF-120
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
4300-4600USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Application :
5 gallon Bottle water filling
Capavity :
100-1200 bottles per hour(for 18.9L bottle)
Automation level :
Automatic
Material :
SUS304
Installation :
Provided
After sale :
Provided
Power :
1.38KW
Weight :
400kg
Description

Description of 100-120BPH complete PET / PC 3 to 5 gallon water bottling machine

We can supply the whole 5 gallon water packing line, the core of the whole line is the Monoblock 3 in 1 rinser-filler-capper part, first the gallon bottle need to be washer and the cap need to be unplugged, then the 1.2 part reins the bottle, fill the gallon bottle and cap the bottle. When the gallon bottle automatically get out, we can check if there's any Dirty matter in the water by checking the light checker, workers need printer the Production Date on the sleeve label by Solid Ink Roll Coding Machine and manually put the sleeve label on the mouth of gallon bottle, after the shrink tunnel, the label will shrink well.

Equipment list:

Items Name of machine Model Size(mm) Qty.
1.1 Semi-auto de-capper and brush washer with full SUS304 BS-1 900*900*1250 1set
1.2 Monoblock rinser-filler-capper with full SUS304 QGF-120 3400*780*1950 1set
1.3 Light checker / / 1pc
1.4 Roller conveyor / / 2m
1.5 Label shrink tunnel / 600*600*1000 1set
1.6 Solid Ink Roll Coding Machine LB-380F 440*345*300 1set

Monoblock rinser-filler-capper

Principle:

This machine is integrated with jar washing-filling-capping functions together;

Worker loads empty jar on jar holder manually, the jar holder with jar will be transferred in advance for jar washing, the transmission force is by gear cylinder;

Washing will be devided into 3 parts, 1st process is by disinfectant fluid, 2nd process is by recycle water washing, 3rd process is by pure water;After washing, the jars will be falling down on angle plate from jar holder by transmission chain with gravity force; Then the jars will be pushed by pushing cylinder to under filling head, then filling start; Filling volume can be controlled by filling time set up. The filled jars will be pushed to under capping head by empty jars afterwards. Worker put lot of disordered caps into cap loader, cap loader will sort cap automatically to load down into cap rail. When filled bottles passing under capping head, cap will fall down onto jar neck, then capping cylinder will do the capping automatically by cap pressing cylinder.

Characters:

1, The whole machine is controlled by PID system, all cylinder travel is calculated in advance for driven distance;

The machine can work under automatic model, manual model is for machine checking;


PID microcomputer system control

Parameters:

Rinsing pump 1: 0.37KW

Rinsing pump 2: 0.37KW

Filling pump: 0.55KW

Cap sorting motor: 0.09KW

Dimension: 3100*570*1450mm (cap loader at side)/2700*570*1720mm (cap loader at top)

+ 2000mm conveyor

Weight: 400kg

Spare parts for free:

Sealing ring for filling valves*1suit

100-120BPH Complete PET / PC 3 To 5 Gallon Water Bottling Machine

100-120BPH Complete PET / PC 3 To 5 Gallon Water Bottling Machine
