Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Outer Inner Brusher With Cap Pull Off For 5 Gallon Water Bottling Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
BSC-1
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
700-1000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30sets per month
Delivery Time :
10 working days
Packaging Details :
Sea shipping Wooden case
Application :
5 Gallon barrel washing Machine
Capavity :
150-200 bbls/ hour
Automation level :
Semi-Automatic
Pull lid head number :
1 Pcs
Material :
SUS304
Bottle type :
3-5 Gallon bottle
Dimension :
1300*900*1200mm
Weight :
130KG
Description

Description of Outer inner brusher with cap pull off for 5 gallon water bottling machine

3 / 5-Gal bottle inside and outside brushing machine:
Gallon bottle Washing machine is an essential equipment in the process of empty barrel pretreatment in the drinking water production line, which is usually used with air compressor. In order to meet the needs of most mineral water plants and pure water plants, the bulky empty barrel treatment technology has become simple and automatic. The device integrates the bottle cap and cleans the inside and outside of the barrel, with reliable performance, simple operation and convenient maintenance.

Q1: what is the purpose of this machine?
A1: This machine is used for recycling and cleaning of 5-gallon barrels. At the same time, the inner and outer walls of the barrel are cleaned, and the bottles are cleaned for the 2 times. The second time can be cleaned with water or disinfectant water according to the needs of customers. Pull out the cover. It is easy to operate and ideal for many small waterworks.

Question 2: how to use this machine?
A2: put the used bucket on the right side of the machine, insert the neck into the hole, and step down the pedal to release the cover; then the worker needs to insert the bucket into the clean position in the middle of the machine. After loading the bucket, you need to close the window. Then, the washing machine will start automatically. After cleaning, insert the neck of the bottle into the hole on the left side for a second cleaning or disinfection

Packing informations for each model of machines:

Model Description Packing Qty. Dimensions(mm) Weight
BS-1 de-capper and brush washer

Wooden case

 1Package 900*900*1250 250KG
S-1 brush washer(single station) 1Package 600*750*1150 200KG
BS-2

de-capper and brush washer

(double station)

 1Package 1300*750*1150 300KG
S-2 brush washer(double station) 1Package 1300*750*1150 300KG
BSC-1 de-capper and brush washer with inner rinser 1Package 1200*750*1150 280kg
