Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
RO-3000
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
8500-9500USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Applicable Industries :
bottle water Manufacturing, Hotels, Garment Shops, Building Material Shops, Hotels, Garment Shops, Building Material Shops
Capacity :
3000Liter/Hour
Material :
Wooden cartoon
Filter Media :
Silica sand /quartz sand, Actived carbon and Sodium ion exchanger
Brand of RO membrane :
HYDECANME or DOW brand
Keywords :
RO Water Filtration
Description

Description of 3 ton per hour SUS304 filters and FRP membrane housing water purifying machine

Technical descriptions of 3000LPH RO water treatment machine:
The water treatment system is divided into 4 parts: Pre-treatment, RO unit, sterilization parts and matching parts. RO is the core of the system.
Pre-treatment: Raw water pump, Quartz sand filter, Active carbon filter, Sodium ion exchanger, Cartridge filter, etc. Functions as below:
a, Avoid incrustation generating on membranes surface; ( Includes Fe3,Fe2,CaCO3,CaCO4,SrSO4,CaF2,SiO2,Fe and Aluminum-oxide) ;
b, Avoid colloidal substance and fluidized bed block up;
c, Avoid organism block up;
d, Avoid microorganism block up;
e, Avoid breakage to membranes from oxidizing substance;
f, Make sure stable water production by RO;
g, Make sure no block up from high hardness;

3 Ton Per Hour SUS304 Filters And FRP Membrane Housing Water Purifying Machine
Equipment list of 4000liter per hour reverse osmosis water puifier:

Items Name of machine Model Size(mm) Qty.
1.1 Raw water pump CHL8-30 / 1set
1.2 Quartz sand filter SUS600 φ600*2500 1set
1.3 Active carbon filter SUS600 φ600*2500 1set
1.4 Cartridge filter SUS320 φ320*1600 1set
1.5

RO unit

(anti-scale dosing device included)

 RO-3000 1600*600*1600 1set
1.6 Connection pipes&valves UPVC / 1suit
OPTION
1.7 Sodium ion exchanger SUS600 φ600*2500 1set
1.8 Sodium ion rebirth device 200L / 1set
1.9 Ozone sterilizer T6G 360*260*610 1set
1.10 Injector 25152 / 1set
Replacement cycle of each part of RO machine:
1. Quartz sand: it should be replaced every 15 months
2. Activated carbon: it should be replaced every 15 months
3. PP filter element: it should be replaced every one month
4. RO membrane: it should be replaced every 24 months

Parameters of 4000LPH RO water filter:

Model
 RO-3000L Remark
Production Capacity
3000Liter per hour
Power Supply 220V/380V 50Hz Customized
Operate Power 12.2KW
Raw Water Pump China Nan Fang pump Customized
Quartz Sand Filter φ600*2500MM SUS304 Quartz Sand:150KG
Activated Carbon Filter φ600*2500MM SUS304 Activated Carbon:50KG
Security Filter 20″×5μm PP filter
High Pressure Pump China Nan Fang HangZhou
Customized
RO Membrane RO-8040 3pcs
Membrane Housing FRP material
Sterilizer Device UV or Ozone Generator


This is the Ozone generator for sterilizing the bacteria in the water and make the water safer.
