5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
RO-12ton
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
21000-23000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3sets per month
Delivery Time :
25-30 working days
Packaging Details :
Sea shipping Wooden case
Applicable Industries :
Filtration
Capacity :
12000liters per hour=12tons per hour
Sterilizer :
UV LED Lamp + Ozone sterilizer
Desalting rate :
95-99%
Conductivity of raw water :
≤400μs
Conductivity of pure water :
≤10μs
RO membrane :
8040
Voltage :
AC 220V 18A/ 380V 9A 50Hz
Description

Description of 5 gallon Bottle filling 12ton per hour water purifying machine

Descriptions of 12000LPH RO water treatment machine:
Reverse osmosis (R/O) is a water treatment process in which water is forced through a semi-permeable membrane with very small pores or "pores". The clean water passes through, leaving behind too much impurities to pass through the membrane to be washed away.
The reverse osmosis system is to compress the raw water through a precision filter, granular activated carbon filter, and activated carbon filter, and then pressurize it by a pump, using a reverse osmosis membrane with a pore size of 1/10000μm

Turn high-concentration water into low-concentration water, while mixing industrial pollutants, heavy metals, bacteria, viruses and other impurities with a large amount of mixed water to fully isolate the required physical and

The chemical indicators meet the drinking and sanitary standards, and the output of purified water is the best choice for supplementing human water quality. It is the key equipment of pure water plant.

5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine

Equipment list of 12000LPH RO water treatment machine:

Items Name of machine Model Size(mm) Qty.
1.1 Raw water pump CHL20-20 / 1set
1.2 Quartz sand filter SUS1200 φ1200*2700 1set
1.3 Active carbon filter SUS1200 φ1200*2700 1set
1.4 Cartridge filter SUS400 Φ400*1600 1set
1.5

RO unit

(anti-scale dosing device included)

 RO-12000 4000*600*2000 1set
1.6 Connection pipes&valves SUS304 / 1suit
OPTION
1.7 Sodium ion exchanger SUS1200 φ1200*2700 1set
1.8 Sodium ion rebirth device 300L / 1suit
1.9 Ozone sterilizer T25G 400*280*800 1set
1.10 Injector 48275 / 1set

Option 1.7 Sodium ion exchanger is based on your raw water quality, if the water hardness is high, then this filter tank is necessary.

Apply high quality SUS304, with automatic control system, piping system, includes manhole, hand hole, water distribution device on top and bottom, filter material, it is pressure model.

Main function is to use ion resin to exchange with Ca and Mg ion in the water, then reduce water hardness to avoid carbonate and sulphate generating in the water. It is the way to get soft water.

5 Gallon Bottle Filling 12 Ton Per Hour Water Purifying Machine

Configuration of the RO main part:

ITEM Unit RO-12ton Brand
Flow rate L/H ≥24000
Recovery rate % 50-75
Design pressure MPA 0.8-4.5
Dimensions MM 4000*600*2000
High pressure pump SET CDLF20-10 11KW*1 NANFANG
Membrane housing material PCS FRP(8040-3)*4 Rework
8040 Membrane PCS Polyamide material*12 HYDECANME
Volume of anti-scale dosing device Litre PE-300L*1
Water flowmeter for salinity water PCS 1
Water flowmeter for purified water PCS 1
Low pressure protector for high pressure pump PCS 1
High pressure protector for high pressure pump PCS 1
Pressure gauge for salinity water PCS 1
Pressure gauge for purified water PCS 1
Conductivity meter PCS 1
PLC PCS 1 Mitsubishi

Program controller

(errors alarm)

 PCS 1
Air switch Suit 1 Schneider
Contactor Suit 1 Schneider
Relay Suit 1 Schneider

1). The system can continuously produce water and is highly automated.

2). No need to regenerate chemicals, easy to operate and maintain.

3). The core component of ro system is imported American DOW membrane.

4). Automatically open when the water level is low, close automatically when the water level is high

5). The system automatically flushes the reverse osmosis membrane to reduce the rate of membrane fouling

6). Multi-stage pump water shortage protection

7). Product conductivity meter can continuously monitor water quality online.

8). Low operating cost and long life

9). There is a reverse osmosis controller to make the entire reverse osmosis system run automatically.

10). Easy to control and maintain.

11). Automatic washing film

12). Environmental protection, low power consumption

13) Automatic flushing/back flushing

14) Low pressure/high pressure protection
