Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
RO-15ton
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
27000-29000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3sets per month
Delivery Time :
25-30 working days
Packaging Details :
Sea shipping Wooden case
Source Water Type :
Tap Water, Borehole (Under Ground) Water, Spring River Lake water
Capacity :
15000liters per hour=15tons per hour
HS Code :
8421299090
Applicable Industries :
Manufacturing Plant, Food & Beverage Factory
Conductivity of raw water :
≤400μs
Conductivity of pure water :
≤10μs
Core Components :
Pump, Engine, Motor
Voltage :
220, 380, 440V, 3P, 50Hz
Description

Description of Community supply Dow membrane 15ton per hour water purifying machine

Descriptions of 15000LPH RO water treatment machine:

Reverse osmosis is considered to be an efficient method to eliminate impurities in water (such as toxic heavy metals, namely lead and radium, mercury, chlorinated pesticides, organic matter, turbidity and dissolved solids, bacteria, viruses). Reverse osmosis can remove more than 97% of total dissolved solids (TDS), more than 97% of organic matter (including pyrogens) and more than 97% of bacteria in water.

Reverse osmosis systems are widely used in water treatment, purification of tap water, well water, groundwater, wellbore salt water, brackish water and sea water, pure water and ultra-pure water production. Application areas, such as food processing, bottled drinking water, domestic drinking water, power stations, electronics industry, cosmetics production, pharmaceutical factories and medical treatment (such as hemodialysis). It is the key equipment of pure water plant and ultra-pure water equipment.

flow chart:

Raw water tank → raw water pump → quartz sand filter → activated carbon filter → water softener (optional) → safety filter → reverse osmosis system (including chemical cleaning device) → ultraviolet sterilizer (ozone generator) → pure water storage tank

Community Supply Dow Membrane 15 Ton Per Hour Water Purifying Machine

Equipment list of 15000LPH RO water treatment machine:

Items Name of machine Model Size(mm) Qty.
1.1 Raw water pump CDMF20-30 / 1set
1.2 Quartz sand filter SUS1600 φ1600*3000 1set
1.3 Active carbon filter SUS1600 φ1600*3000 1set
1.4 Cartridge filter SUS500 φ500*1700 1set
1.5

RO unit

(anti-scale dosing device included)

 RO-15000 4000*600*2300 1set
1.6 Connection pipes&valves SUS304 / 1suit
OPTION
1.7 Sodium ion exchanger SUS1600 φ1600*3000 1set
1.8 Sodium ion rebirth device 300L / 1suit
1.9 Ozone sterilizer T30G 400*280*1010 1set
1.10 Injector 48275 / 1set

This is the filter filling material, quartz sand, activated carbon, softening resin, RO membrane, PP filter. these parts need change regularly. If you purchase our machine, the filter filling material is included. After a long time, you can get them from us.

Community Supply Dow Membrane 15 Ton Per Hour Water Purifying Machine

Configuration of the RO main part:

ITEM Unit RO-15ton Brand
Flow rate L/H ≥30000
Recovery rate % 50-75
Design pressure MPA 0.8-4.5
Dimensions MM 4000*600*2300
High pressure pump SET CDLF20-14 15KW*1 NANFANG
Membrane housing material PCS FRP(8040-3)*5 Rework
8040 Membrane PCS Polyamide material*15 HYDECANME
Volume of anti-scale dosing device Litre PE-300L*1
Water flowmeter for salinity water PCS 1
Water flowmeter for purified water PCS 1
Low pressure protector for high pressure pump PCS 1
High pressure protector for high pressure pump PCS 1
Pressure gauge for salinity water PCS 1
Pressure gauge for purified water PCS 1
Conductivity meter PCS 1
PLC PCS 1 Mitsubishi

Program controller

(errors alarm)

 PCS 1
Air switch Suit 1 Schneider
Contactor Suit 1 Schneider
Relay Suit 1 Schneider
