1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
1000BPH 1 Blower 1 Preform Heater 0-2L Bottle Blow Molding Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
BL-1200A
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
5800-6800USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Capavity :
1000-1200bottles per hour
Structure :
1 preform heater + 1 blower
Automation level :
Semi-automatic
Finished bottle :
0-2Liters
Designing ability :
Provided
HP Air Compressor :
1.2m3/min 30Kg
Air filter :
2.0 m3/min 30Kg
Air dryer :
2.0 m3/min 30Kg
Description

Description of 1000BPH 1 blower 1 preform heater 0-2L bottle blow molding machine

BL-1200A 1200BPH semi automatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 10-2000ml. This machine needs the thermoplastic hollow molding equipment that is matched with the injection molding machine, that is, the two-step plastic blow molding machine. The product needs to be made into a preform by an injection molding machine. After it is cooled, it is preheated by the special heater of the machine to make it feel elastic and then placed in the machine to make a hollow container. This machine is equipped with ordinary honeycomb intubation aluminum oven and far-infrared rotary heater. Can be deployed according to the actual situation of the customer. The clamping part of the main machine adopts mechanical double-boom clamping, so as to ensure that there will be no expansion under high-pressure blowing.

Machine advantages of BL-1200A 1200BPH semi automatic bottle blow molding machine:
1. Small size, low power consumption, convenient operation and maintenance;
3. Advanced PLC control system, time control can be accurate to 0.01 second.
4. Special air storage device.
5. Infrared preform heater.
6. Different heating lamps are equipped with independent temperature control devices to ensure the ideal heating effect of the preform.
7. The direction of the heating lamp can be adjusted according to different preforms.
8. Only one person is required to operate and no special training is required.
9. Easy to install and start.
10. The scrap rate of finished products is less than 0.2%.

Equipment list BL-1200A 1200BPH semi automatic bottle blow molding machine:

Items Name of machine Model Size(mm) Qty.

1.1

 Semi-automatic blow molding machine BL-1200A

1600*600*1610

1870*630*1450

1set

1set

1.2

 HP Air Compressor 1.2m3/min 30Kg 2000*1000*1400 1set
1.3 Air filter 2.0 m3/min 30Kg 750*350*350 2sets
1.4.1 Blow mold 500ml / 1set
Mould will be finalized as client’s designs
OPTION
1.5 Air dryer 2.0 m3/min 30Kg 1050*650*1100 1set
1.6 Mould Chiller 3HP 1100*680*1200 1set
Main parameter:
Model BL-1200A
　　 Container Product material PET,PP
Volume 0.1-2
Theoretical output 800-1000
Preform length 15-350
Preform inner diameter Φ5-38
　　 Moulding Max.mould plate Dimension(L x W) 350×380
Max.mould thickness 180
Clamping force 45
Mould opening stroke 16
　　Machine size and weight Main machine (L x W x H) 160×60×161cm
Main machine weight 500
Heater (L x W x H) 187×63×145cm
Heater weight 250
Power 17.5
