Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
BL-5000
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
28000-30000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5sets per month
Delivery Time :
20-35 working days
Packaging Details :
Sea shipping Wooden case
Name :
Automatic 5L PET bottle 1 cavity blow molding machine
Capavity :
800-1000bottles per hour(for 5L bottle)
Cavity :
1 cavity
Suitable bottle :
100 ml to 5000 ml
Installed Capacity Power / Actual Usage Power :
15kw/10kw
Applicable bottle neck :
15mm-60mm
Applicable bottle body diameter :
20-200mm
Applicable bottle height :
50mm-350mm
Description
Description of Auto 800BPH 3L 4L 5L water plastic bottle 1 cavity blow molding machine

BL-5000 type Automatic blow molding machine is suitable for blowing PET bottles of various shapes, volume from 100 ml to 5000 ml, wide application for blowing mineral water bottles, soda bottles, cola bottles..etc

BL-5000 series automatic bottle blowing machine can stretch and blow 3L-6L oil bottles, 1-8L large wide-mouth bottles and various special-shaped large-volume bottles. The machine has one out of one, one out of two, and one out of four automatic 5L oil bottle blowing machines.
The automatic oil bottle blowing machine is controlled by imported electrical components, which has the advantages of high performance, strong stability, and simple operation.
It has a unique lamp tube installation method, which is suitable for different tube blank heating.
BL-5000 bottle blowing machine adopts infrared tube heating. Strong penetrating power, uniform heating, adjustable reflector width and height, suitable for heating preforms of different structures.
The automatic blow molding machine uses pneumatic components from well-known brands such as Germany and Japan, which has high sensitivity, fast switching speed, low failure rate, and safe and reliable operation.

Blow molding machine is a kind of equipment that makes plastic particles into hollow containers through blow molding process. At present, the more common models include one-time hollow extrusion blow molding machines that use PP and PE, and use PET, PC or PP for two-time molding. Injection stretch blow molding machine
At present, most of the blow molding machines are still two-step blow molding machines, that is, plastic raw materials must be made into preforms before blowing.
The tubular plastic parison obtained by extrusion or injection molding of thermoplastic resin is placed in a split mold while it is hot (or heated to a softened state), and after the mold is closed
Immediately pass compressed air into the parison to inflate the plastic parison and adhere to the inner wall of the mold. After cooling and demolding, various hollow products can be obtained.

Equipment list of 800BPH Automatic 5L PET bottle 1 cavity blow molding machine:

Items Name of machine Model Size(mm) Qty.
Linear 1 cavity Bottle Blowing System
1.1 Blow Molding Machine BL-5000 2508*1858*1920 1set
Preform unscramble 2000*950*2480 1set
1.2 HP Air Compressor 1.2 m3/ min 30Kg 1880×850×1050 1set
1.2.1 HP Air storage Tank 0.6 m3/ min 30Kg 1200*1200*1650 1set
1.2.2 HP Air Filters 3.0 m3/min 30Kg 750*350*350 2sets
1.2.3 HP Air dryer 2.0 m3/min 30Kg 1100x650x1100 1set
1.3 LP Air Compressor 2.0 m3/min 10Kg 1780*840*1455 1set
1.3.1 LP Air Filters 2.0 m3/min 10Kg 750*350*350 2sets
1.4 Mould Chiller 5HP 850*560*870 1set
1.5 Aluminum Blow mould 5000ml 1cavity 1set
1.6 Connecting pipes 2.0 m3/min 30Kg / 1suit
Main parameter of 800BPH Automatic 5L PET bottle 1 cavity blow molding machine:
Model BL-5000
　　Container Product material PET
Volume 0.1L-5L
Theoretical output 800-1000PCS/H (5L)
Applicable bottle body diameter 20-200mm
Applicable bottle height 50mm-350mm
Applicable bottle neck 15mm-60mm
　　Mould Cavity 1 cavity
Mold effective area 350*450mm
Host machine Power Voltage 380v 3Phase /220v 3Phase 50/60HZ
Installed Capacity Power / Actual Usage Power 15kw/10kw
Cooling water Quantity 15L/min
Host machine size L/W/H Weight 2508*1858*1920mm/3600kg
Unscramble size L/W/H Weight 2000*950*2480mm/250kg
