Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
MB-350B
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
20000-21000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Name :
Double rows linear type film shrink packing machine
Capavity :
40packs per minutu
Compressed air consumption :
0.3M3/min; 0.6-0.8mpa
Total power :
53 KW
Weight :
3000kg
Whole plant size :
L12200×W1360×H2000mm
350/500ML bottles package :
4×6, 4×5
1L/1.5L bottles package :
3×3, 3×4
Description
Description of 40 packs per min Film cutting shrink heating packing bottle wrapping machine

Device Description:
The linear heat shrink packaging machine is based on the heat shrinkage characteristics of the packaging film. It uses photoelectric switch sensors to detect online. The collected signals are controlled and processed by a PLC (programmable controller) program. The conveyor belt is used for continuous bottle feeding, clamping and placing. Bottle, continuous push rod push the bottle to wrap film, heating and cutting knife to seal and cut into packages, heating channel contraction, cold air cooling and shaping and other mechanisms to complete the whole process.
It is specially designed for automatic packaging production lines for bottled items such as beer, beverages, purified water, juice, and dairy products.
It has the fully automated functions of conveying and feeding, film wrapping, sealing and cutting, shrinking, cooling and shaping.
Using the world's advanced film constant temperature heat sealing technology, the seal is clear and firm.
The rapid cooling structure of the sealing ensures higher sealing strength under high-speed production conditions.

Main structure and produce process of 40packs Double rows linear type film shrink packing machine:

Main structure: the equipment is made of bottle feeding conveyor part, Bottles sorting part, Film cutting packing part, shrink heating tunnel, fan chilling part, roller conveyor output part and electric control system, pneumatic control parts and so on.

Produce process: MB350B automatic linear packing machine is produced at the basis theory of the film shrinking after heated. The whole packing process is including photoelectric sensor testing, PLC treats the collected signal, convey belt delivering the bottles, the dividing board divide the bottles into lines and the push the bottles

Technical parameter of 40packs Double rows linear type film shrink packing machine:

Model MB-350B
Whole plant size L12200×W1360×H2000mm
Bottle inlet and film cutting part L7200×W1360×H2000mm
Shrink tunnel part(include roller conveyor) 5000×1360×1450mm
shrinkage film material: PE
Suggested shrinkage film thickness 0.07-0.15mm
Shrinkage tunnel max temperature 180 - 220° adjustable
max output per minute 30-40 bags
Weight 3000kg
Compressed air consumption 0.3M3/min; 0.6-0.8mpa
Inlet bottle convey belt width 926mm
Fan 0.39KW; 6 sets fans, 65W for each;

● Power-- Shrink tunnel and cooling part:48KW (Include 6 PCS of fan, each fan with 65W);

Power for host machine part(5KW);

Total power: Amount 53 KW

● Standard voltage: 380V 3Phase 50HZ(can be customized as customer request)

Recommended package type of 40packs Double rows linear type film shrink packing machine:

(1)350/500ML bottles package: 4×6, 4×5; 550/600ML bottles package: 3×4, 3×5.

(2)1L/1.5L bottles package: 3×3, 3×4; 2L/2.5L bottles package: 2×2, 2×3.

(3)Regarding tin cans, we suggest adopt to package with carton tray, pack steadily.

Remark: Minimum support package size: 200*150*100mm;

Maximum support package size: 420*300*330mm;
