3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
DCGF32-32-10
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
2000-160,000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5sets per month
Delivery Time :
25-30 working days
Packaging Details :
Sea shipping Wooden case
Name :
Carbonated soft drink processing filling packing
Capavity :
8000 bottles per hour
Applicable bottle :
0-2L bottle
Control :
PLC+ Touch Screen
Pet bottle volume :
0-500ml
Washing-Filling-capping heads :
32-32-10
Machine material :
Stainless Steel SUS 304/316
Filling Accuracy :
±2ml
Description
Description of 3 in 1 monobloc SUS frame bottle soft carbonated drink filling line


Description:

This carbonated drink mixing machine is made with the newest technology which introduced from Japan.It is in the leading position
comparing with similar production in China.The mixer is mainly suitable for mixing process of all kinds of carbonated drink.
It is also used in mixing slurry drink,fermented drink and other drinks.
1. Automatic with alarm:The pressure in all tank and the liquid level if the machine are all controlled automatically with PLC.
Once a error occures,the alarm lamp will light and the alarm ring will sound and the mixer stop automatically.
2. Easy operation and regulation:The operation of mixer is especially convenient Only turn around the buttons according to
the pre -set program,the normal operation can be carried out.The production capacity,water- sugar proportion and gas content can be adjusted without exchanging any parts.
3. Even mixing and accurate proportion:One time mixing process is adopted,so the mixture is even.The mixing proportion of
water and sugar is strictly controlled with measuring needle valve with fine regulation,Its precision can reach about 0.05%.
4. Even gas content:It has a battle heat exchanger to cool the sugarwater mixture and carry out twice carbonating.
So its carbon content is especially high.


Equipment list of 8000BPH soft carbonated drink filling line:
First part is the RO water treatment system, please check the following parts.

2,4000LPH carbonated drink preparation line:
2.1Syrup melting pot500KG/h∮800*16001set
2.2Syrup Filter500Kg∮320*8001set
2.3Mixing tank2000L∮1300*22003set
2.4Water chiller0240WST22585*900*13351set
2.4.1Cooling towerHT-60∮2580*23501set
2.4.2Cooling water pump100-100A10m lift1set
2.4.3Chilling water recycle pump100-100A10m lift1set
2.5CO2 filter6m3/h∮500*14001set
2.6CO2 mixing carbonatorQHS-4000-22150*1400*24001set
2.7Heat resistant pump/ beverage pump//3sets
2.8Connection piping system//1suit
3,8000BPH-500ml carbonated energy drink filling-packing plant:
3.1Balanced pressure 3 in 1 unit DCGF32-32-108000BPH3800*3200*24501set
3.1.1Air conveyorFS-12.2m1set
3.1.2Belt conveyorSYS-14m1set
3.1.3Light checkerDJ-18001pc
3.1.4Cap lifterTSJ-1800*800*28001set
3.2Bottle warming machine8000-10000BPH8000*2000* 18501set
3.3Bottle dryerCG-21500*500*16001set
3.4Online ink jet code printerVJ1210345*285*5411set
3.5OPP hot melt glue labeling machineOPP-3003200*1524*20001set
3.6Automatic PE film shrink packing machine12packs/min5050*3300*21001set
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
3 In 1 Monobloc SUS Frame Bottle Soft Carbonated Drink Filling Line
