18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
18 Head Beer Beverage 500ml Tin / PET / Aluminum Cans Filling Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
BGF18-4A
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
40000-45000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3sets per month
Delivery Time :
25-30 working days
Packaging Details :
Sea shipping Wooden case
Application :
18 head 2 in 1 balance pressure can filling machine
Capavity :
4000-7000cans per hour
Material of can :
Aluminum can
Filling material :
Beer, soft carbonated drink, soda, liquid with gas
Power :
4.5KW
Pressure :
max 0.4Mpa
Dimension :
2100*1800*2000mm
Weight :
4000kg
Description
Description of 18 head beer beverage 500ml tin / PET / aluminum cans filling machine
The production line of canned beverages mainly includes: water treatment equipment, beverage mixing system, depalletizer, empty can washing machine, can filling and sealing machine, sterilization pot, cage unloading equipment, blow dryer, can turning machine, inkjet printer , PE film heat shrink packaging machine or carton packaging machine.
Fully automatic or semi-automatic empty can (bottle) depalletizer: mainly suitable for automatic depalletizing of three-piece cans, two-piece aluminum cans and glass bottles. The empty cans (bottles) stacked on the pallet are pushed up to the conveyor layer by layer, and then conveyed to the chute type can washer or automatic bottle washer by a multi-line conveyor or turntable, instead of manual cans (bottles). ),Increase productivity. PLC programmable computer automatic controllers, photoelectric switches, travel switches, pneumatic controls, etc., all adopt well-known brands such as Germany, Japan, and Taiwan.
Spray can washing machine: It automatically sprays and sterilizes the inner cavity and outer surface of the can, and the material is stainless steel. When flushing the cans, first turn the cans into the can washer, and spray down the side and down through a porous warm water pipe. The cans will rotate 0.5 meters to achieve the purpose of cleaning, and then the cans can be turned into the next conveyor chain. Tao. It is necessary to pay attention to the tank not to be interrupted in the chute, so as to prevent the fast irrigation speed and the unclean water control.
Filler
1) Balance filling method.
2) High-pressure foam stimulator is equipped to minimize air remaining at the neck.
3) Centralized automatic lubrication system, simple for maintenance.
4) Filling level tolerances : ± 2.0 mm
5) Bottle break rate : max. 0.01% (1:10,000)
6) With perfect CIP cleaning function, and capable of rinsing filling pipes with acid, lye liquid and hot water.
7) All the materials in contact with the valves, tanks, pipes are made of stainless steel 304 materials, inside and outside the wall of mirror-polished, ensuring it is healthy.
Parameters of the whole 18 head 2 in 1 balance pressure can filling machine:
Power: 4.5KW
Dimension: 2100*1800*2000mm
Weight: 4000kg
Pressure: max 0.4Mpa

Equipment list of the whole 18 head 2 in 1 balance pressure can filling line:

Items Name of machine Model Size(mm) Qty.
1.1 Semi auto can depalletizer SXDJ 2500*1500*2500 1set
1.2 Tunnel type can washer XG-1 1500*300*1500 1set
1.3 Monoblock beer can filler-sealer BGF18-4A 2100*1800*2000

1set
1.3.1 Inlet belt conveyor SYS-1 / 2m
1.3.2 Outlet belt conveyor SYS-1 / 4m
1.3.3 Light checker DJ-1 / 1set
1.4 Bottle blow dryer CG-1 1000*600*1800 1set
1.5 Reverse device / / 2sets
1.6 Ink jet code printer OH-338 347*220*100 1set
1.7 Automatic case erector EB-10P 2000*1900*1500 1set
1.8 Automatic case filler (grasper type) 01GDA 4900*1200*2100 1set

With 2.4m belt conveyor to connect case erector to case filler for empty case

And with 2.4m bottle division conveyor for bottles incoming
1.9 Automatic case sealer FX-6050 3720*950*1770 1set
With 2m roller conveyor for case outlet
