Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
CG-12+FBZ-1
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
10000-12000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5sets per month
Delivery Time :
25-30 working days
Packaging Details :
Sea shipping Wooden case
Name :
Liquid nitrogen filler device for tea milk juice cans filling machine
Filling speed :
50-2000B/min
Current :
≤5A
Used for :
Milk, tea, energy drink, wine, juice beverage
Rated input voltage :
110VAC-60Hz/220VAC-50Hz +/-10%
Humidity :
Relative humidity 0%-100%
Working elevation :
suitable in elevation of 3050 meters(10000FT)
Total weight :
32KG
Description
Description of Liquid nitrogen filler device for tea milk juice cans filling machine

The role of the can nitrogen filling machine:
Before the filling is completed and entering the sealing, the modern liquid nitrogen filling technology is used to accurately drip the liquid nitrogen at -196℃, and then the liquid nitrogen is immediately sealed. The liquid nitrogen absorbs heat and expands 700 times into gas nitrogen in a short time.
For one thing, internal pressure is generated in the can/bottle, so that the bottle will not be collapsed after cooling, and it will not be deformed during packaging and handling.
Second, the air (especially oxygen) in the can/bottle is driven away to make the product shelf life longer and taste better.
Three rules, aluminum cans are not easy to rust and are suitable for refrigeration.
More importantly, the original tinplate cans are changed to aluminum cans. Aluminum cans are much lighter than iron cans. A general aluminum can is 13 grams. An iron can with the same volume requires 45 grams; while the original 18 grams of PET bottles only need 12 grams or 12 grams. The handle of a lower gram after filling with liquid nitrogen is no less than an 18 gram bottle; this greatly saves the material cost of the can/bottle and can reduce the cost of handling and transportation.
Advantages:
PET bottle lightweight — reduce the weight of PET, save cost and environmental protection
Extend the shelf life-reduce oxygen content
Glass is changed to plastic packaging-to eliminate the personal hazard and weight of glass bottles
Easy to label—The bottle wall has the same hardness, which improves the efficiency of labeling
Bottle robustness — maintain the original shape of the lightweight bottle
Reduce the use of oxygen-the saving performance of liquid nitrogen filling can be measured and replicated
Eliminate flat bottles — increase bottle compression to eliminate the problem of flat bottles
Increase the utilization rate of warehouse space-increase product stacking capacity and reduce usage area
low oxygen function-inert packaging to maintain product freshness
Maintain the quality of organic products-no preservatives are needed to extend the shelf life
The adjustable speed of liquid nitrogen dripping machine and the high-efficiency vacuum liquid nitrogen insulation pipeline ensure the low limit of liquid nitrogen consumption.
The advanced nature of the filling valve of the liquid nitrogen dripping machine ensures that pure and single-phase liquid nitrogen can be delivered.
The low outlet pressure of the filling valve of the liquid nitrogen dripping machine ensures that the spray of liquid nitrogen is smaller.
The liquid nitrogen dripping machine has no frosting operating environment.
Adjustability of the filling amount and filling time during the operation of the liquid nitrogen dripping machine.
The liquid nitrogen dripping machine can continuously self-monitor the system through the alarm indicator.
Liquid nitrogen dripping machine PLC control / touch screen / user interface language optional.
The liquid nitrogen dripping machine can be directly connected to the liquid nitrogen vacuum insulation pipeline, and can provide a complete liquid nitrogen supply system from the liquid nitrogen storage tank to the filling line.
The small shape and simple installation of the liquid nitrogen dripping machine are suitable for any filling line.
The diversity of liquid nitrogen dripping machine models ensures that it can match the speed and application of any assembly line.

Specifications

Rated input voltage: 110VAC-60Hz/220VAC-50Hz +/-10%

Current: 〈=5A

Humidity: Relative humidity 0%-100%

Working elevation: suitable in elevation of 3050 meters(10000FT)

Noise: Lasting noise〈=78dB(A)

Total weight:32KG

Filling speed: 50-2000B/min

Configuration

Touch screen 1pc Siemens-Germany
PLC 1pc Siemens-Germany
Sensor 2suits Omron
Liquid nitrogen heater 2pcs
HP dosing magnetic valve 1pc MAC-American
High speed air cylinder 1pc BEAN BULLY-American
Low temp resistant doser 1pc Germany
Titanium stick Filter 1pc
