Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
Preform
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
0.496USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 per 10days
Delivery Time :
7-15 working days
Packaging Details :
Sea shipping Wooden case
Product name :
5 gallon water bottle preform
Material :
PET
MOQ :
5000pcs
Weight :
From 320 gram to 800 gram
Used for :
Blowing 3 - 5 gallon bottle
Color :
Blue,green etc.
Neck :
55mm
Carton size :
58*43*18 26pcs/ct
Description
Description of 600g 650g 680g 700g 730g 750gram 20L barrel 5 gallon bottle PET preform

PET raw material characteristics:
PET raw material has the characteristics of low heavy metal content, low acetaldehyde content, good color value and stable viscosity. Due to the unique process formula and production technology, the product has excellent processing performance, low processing temperature, wide processing range, high product transparency, and high yield, which makes the bottle manufacturing process high in production efficiency and low degradation. The low aldehyde content effectively guarantees the unique tastes of purified water, mineral water, and distilled water while ensuring hygiene and safety. PET bottle has the advantages of stable structure, strong gas barrier, low water absorption, light weight, strong toughness, transparency and good gloss. It has become the mainstream of a new generation of beverage packaging products. At the same time, it is also in the market of alcohol and condiments. Shows increasing competitiveness.


PET product performance:
It has good mechanical properties, the impact strength is 35 times that of other films, and the folding resistance is good.
It is resistant to oil, fat, dilute acid, dilute alkali, and most solvents.
The permeability of gas and water vapor is low, and it has excellent gas, water, oil and peculiar smell resistance.
It has high transparency, can block ultraviolet rays, and has good gloss.
It is non-toxic, tasteless, and has good hygiene and safety, and can be directly used for food packaging.


The advantages of PET 5-gallon preforms:
No BPA
Environmental protection of raw materials
No plasticizer
100 brand new materials, generally 5 gallon tube embryos with good transparency cannot be made from recycled materials
Cost is lower than PC barrel
Good transparency and gloss

The specifications of the 55-neck preform are as follows:
Weight of 5-gallon preform: 800G 750G 730G 700G 680G 66G 650G 620G 600G 580G
3 gallons, 4 gallons preform weight: 560G 530G 480G 430G 400G 350G 320G

Remarks: The detailed specifications of only 55 preforms are listed above. In addition, the blown volume of the preform suggested above is for reference only, and the specific volume of the blowable bottle in gram weight should be based on the specific bottle shape and the thickness effect required by the customer.

For the specifications and detailed dimensions of 30-mouth, 38-mouth, 45-mouth, 48-mouth, and 28-mouth water bottles, beverage bottles, oil bottles, please refer to the website for detailed information descriptions specifically for these products.

3-5 Gallon Preform
Item Product Name Weight

Neck

(mm)

MOQ
1.1 5 Gallon preform 800G

Φ55

5000pcs

750G
730G
700G
670G
645G
1.2 4 Gallon preform 580G
530G
475G
1.3 3 Gallon preform 450G
400G
350G
320G

Our Gallon preform packing details:

Weight Carton size (cm)

Number of cases packed

(PCs/box)

20' Container

(Number of cartons/number of preform)

800G 58*43*18 26 650/16900
750G 58*43*18 26 650/16900
730G 58*42.5*18 26 650/16900
700G 58*42.5*18 26 650/16900
680G 58*41*17.5 26 722/18772
660G 58*41*17.5 26 722/18772
645G 58*41*17.5 26 722/18772
580G 58*22.3*38 34 530/18020
480G 56*27*36 43 518/22274
450G 56*27*36 43 518/22274
400G 55*32.5*33 51 478/24378
350G 53*32*33 51 492/25092
320G 53*32*33 51 492/25092
