IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting
Specifications
Place of Origin :
China
Brand Name :
MF
Certification :
CE, RoHS
Model Number :
MF-Y023W
MOQ :
100PCS
Price :
Negotiable
Packaging Details :
43.5*31.2*31.2cm/6pcs, G.W: 12Kg
Delivery Time :
Depends on orders
Payment Terms :
T/T, Western Union, L/C, Paypal
Supply Ability :
5,000pcs/Month
Model No: :
MF-Y023W
Input Voltage: :
AC 85 -265V
LED Power： :
23W
LED Chip: :
Samsung
LED Driver: :
Meanwell
CCT: :
3000K -6500K
IP Rating: :
IP65
Description

Waterproof Ra70 23W LED Courtyard Lighting Natural White Outdoor Walkway Lighting

Quick Detail:

  1. 23W LED courtyard light
  2. Input: AC 85V-265V, 50/60Hz
  3. Luminous Flux:≧2100 Lm
  4. CRI: 70
  5. Brand chip: SAMSUNG
  6. LED Driver: Meanwell
  7. Adjustable: -15 to +15
  8. IP:65
  9. CE, RoHS certificated

Description:

Excellent manufacturers of LED street lights in china, Ming Feng Come out LED courtyard light series in 2011. These LED street lighting series combines all street LED lighting features together including economic, long lifespan and environment protection. Applied with the best LED from SAMSUNG, the street light attains over 78 lm/w illumination efficiency. Accelerated by Professional Unique Optical Lens, Ming Feng LED street light distribute all the light onto road with maximum effect.

LED courtyard light embrace typical European and American style solid and slender , flexible current driving range , thermal and optical integrated modular system , the light distribution of multiple choice , free tool for installation and maintenance, complete solutions , widely applicable installation transition from the old and the various control methods.

Specifications:

Item

MF-Y023W

Input voltage

85-265Vac 50Hz/60Hz

LED Power

23W

Rated Power

28W

Delivered Flux(Tj80°c)

2100lm

IP Rating

IP65

LED QTY

50 pcs

Color temperature

3000K-6500K

LED Chip

SAMSUNG

LED Driver

Meanwell

Color Rendering Index

Ra>70

Power Factor

>0.9

Lifespan

≥50,000hrs

Operation Environment

Temperature:-40°C~50°C/Humidity:10%~95%

Material

Aluminum Alloy

Product Size(mm)

374(L)*114(W)*112(H)

Packing Size(mm)

422(L)*148(W)*128(H)/pcs

Net Weight

0.9Kg

Gross Weight

1.1Kg

Certificate

CE/RoHS

Warranty Period

5 years

Competitive Advantage:

1. Die-cast roadway light

2. The light source use 100M/W SAMSUNG chip, the luminaire reach 78M/W

3. Beautiful appearance for the shell

4. High efficiency driver system from Meanwell

5. The product is suitable for use in the streets, walkways, park, garden light, etc

6. Warranty:5 years

Light Distribution Curve:

IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting

Product Size:

IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting

Installation Diagram Description:

1. Installed on the pole

IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting

2. Installed on the wall

IP65 Ra75 23W LED Courtyard Light 2100Lumen 4500K Outdoor Walkway Lighting

Applications:

The product is suitable for use in the streets, walkways, park, garden light, etc.
