600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
Specifications
Brand Name :
MF
Model Number :
MF-FL-600S
Certification :
CE, RoHS, ETL,SAA CB,DLC, TUV
Place of Origin :
China
MOQ :
1PCS
Price :
Factory price !!
Payment Terms :
T/T, Western Union, L/C, Paypal
Supply Ability :
5,000pcs/Month
Delivery Time :
1 week for sample, 2 weeks for bulk order
Packaging Details :
770(L)X 600(W)X 223(H)MM/1PCS/CTN, N.W: 24.0Kg G.W: 25.7kg. 274 CTN/20ft
Power :
600Watt
Input :
90-305Vac, 50/60Hz
Chip Brand :
Lumileds 3030 or Lumileds 5050
LED Driver :
Meanwell
Beam Angle :
30°，60°, 90° , 120°，60°x135°,85°x135°
IP Grade :
IP67
House Color :
Black in stock, grey,white as options
Efficiency :
130lm/Watt,160lm/W optional
CCT :
3000K / 5000K / 6000K
Dimmable :
Zigbee,Microwave,Day light sensor, DALi,DMX512
Warranty :
5 Years and 10 years @ conditions
Lifespan :
9 years@ 15 hours daily
Operating Temp :
-30℃~+45℃
THC :
<15%
Description

600W LED contruction lights for construction zone,outside building,sporting area,sea port.

Data sheet download by clicking MF-FL-600S Tech Data sheet.pdf


Specifications:

Item

MF-FL-600S

Input voltage

85-265Vac 50Hz/60Hz

LED Power

588W

System Consumption

600W

Delivered Flux

600x130lm,600x160lm

IP Rating

IP67

Beam Angle

30°,60°, 90° and 120° ,asymetric lens 135°x60° and 135°x85°

Color temperature

3000K / 5000K / 6000K

LED Chip

 Lumileds

LED Driver

Meanwell

Color Rendering Index

Ra>80,70 as options

Power Factor

≧0.90
Color of Housing Black in stock, grey, white as options

Lifespan

1000,000hrs @ conditions, regular life span:50,000 hours, 9 years.

Operation Environment

Temperature:-30°C~45°C/Humidity:10%~90%
Storge Temperature -40°C~+50°C(@25°C)

Material

Anti-corrosion Die Cast Aluminum Alloy

Product Size(mm)

763(L)x 506(W)x 148(H)

Net Weight

24.0 Kg/PCS. 1PCS/CTN

Certificate

CE/RoHS/TUV/ETL/GS/SAA/FCC/DLC

Warranty Period

5 years,and 10 years @ conditions


Competitive Advantage:

1.Lumileds chips, 130lm/w or 160lm/W, CRI up to Ra80. Junction temperature <75°C.
2.World Calss Brand, MeanWell LED Drivers, wide AC90V~305V, PF>0.98, low THD<15%.Built-in Mean well drivers, make the lamp safer for operation.
3.L70>80,000hrs. Design lifespan 100,000hrs @ conditions.9 years @ 15 hours/day.
4.Adjustable to project aimed lighting area accurately.
5. Constant current design, much more reliable in life-span.
6. Japan secondary optical DIWL lens, light transmittance up to 92%.
7. Intelligent dimming system, 1-10V, Dali, PWM dimming models are available

8. Certificated: CE, TUV, RoHS,ETL,CB,SAA, FCC, DLC

IP67 LED Construction light power range:

600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting

Model Number MF-FL-80S MF-FL-100S MF-FL-150S MF-FL-200S MF-FL-250S MF-FL-300S MF-FL-400S MF-FL-500S MF-FL-600S
Lumen Output 10,400lm 13,000lm 19,500lm 26,000lm 32,500lm 39,000lm 52,000lm 65,000lm 78,000lm
Wattage 80W 100W 150W 200W 250W 300W 400W 500W 600W
Luminous Efficiency 130LM/W, 160LM/W for choose
CCT 2000K-6500K
CRI 70+, 80+ Ra for option
Beam Angel 30°, 60°, 90° , 120°, 60°x135°,85°x135°
Inut voltage 100-240Vac/180-528Vac, 50/60Hz PF>0.97
IR Rating IP67
LED Driver Meanwell
HID Equivalent 150-200W 250W 300-350W 400-450W 5000W 600-700W 800-900W 1000-1100W 1200-1500W
Certficated ETL, SAA, CE, FCC, ROHS



Application photos

600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting

600W LED Construction Lamp Microwave 10KV Surge Protection For Area Lighting
