Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Specifications
Brand Name :
MF
Model Number :
MF-624
Certification :
CE, RoHS
Place of Origin :
China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
20,000pcs/Month
Delivery Time :
Depends on orders
Packaging Details :
67*27*24cm, 11kg
Product Item : :
LED Tri-proof light
Type : :
T5
IP rate : :
IP65
IK rate : :
IK08
Power : :
20W/30W/40W/60W
LED quantity(pcs) :
120/192
CRI :
>80RA
Luminous efficiency(lm) :
2044.72/ 3082.5
Length :
2ft/4ft/5ft
Application :
Supermarket,office,Factory,Parking lot,School
Description

LED Tri Proof Light For Indoor And Outdoor 100-277VAC IP65 Rated Polycarbonate Housing


Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated

  1. IP65 Tri-proof LED Light Fixture
  2. Input: AC 100-277V, 50/60Hz
  3. Luminous Flux: 140lm/w±10%
  4. CRI: >85
  5. PF: >0.95
  6. Lifespan: ≧50000Hrs
  7. IP rate: IP65
  8. IK rate: IK08


Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
*Slotted iron Board, excellent heat dissipation.
*Driver: Meanwell or other Chinese brand options.
*IP65/IP66, IK08, and 850 degrees glow wire test requirement.
*Microwave sensor and PIR sensors, emergency kits, etc. It can be easily available and installed.
*Modular installation,save labor cost.
*Suitable for supermarket, warehouse, underground parking place, garage, productionplant, suitable for outdoor and wet location lighting application.
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated

Model No. MF-624-20WMF-624-30W MF-624-40Ww MF-624-50w MF-624-60w MF-624-50W-5MF-624-60wW-5MF-624-80W-5
Dimension(mm) 60Ox83x68 1200x83x68 1500x83x68
Input voltage AC220-240V
Frequency 5OHz to 6OHz
Power 20w 3ow 40w 5ow 6ow 5ow 6ow 8ow
PF conversion >0.95
Power supply Mean Well or MF CE TUV driver
LED quantity(pcs) 120 192 240 288 336 288 288 432
LED brand TAIWAN EPISTAR
LED type 2835 LED
Luminous efficiency(lm) 2044.72 3082.5 4111.33 5250.356069.02 5163.78 6045.62 8247.35
Color temerature 30OoK / 400oK l 5ooOK / 600oK
CRI 80-90
Beam angle 120
Warranty 5 Years
Approval CERoHS
Main materials Aluminum Housing +PC Milky Cover/Stripped Cover
lP rating IP65
Life span 5o,000 hours
Standard packing 6pcs/ctn 6pcs/ctn 4pcs/ctn 4pcs/ctn 4pcs/ctn 4pcs/ctn 4pcs/ctn 4pcs/ctn
G.W(kg) 11 11 12 13 13 15 15 16
Carton Size(mm) 67x27x24 127x24x20 157x24x20
operating temperature -20"C~+50C
Storage temperature -40"℃~+85"℃


Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated

Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 RatedPolycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated



Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated


Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated

Installation:
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated​

Connection Type:

Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated



Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 RatedPolycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated
LED Tri-Proof Lights are ideal for use in industrial facilities, commercial kitchens, parking garages, and other harsh environments where bright, efficient lighting and protection from dust, moisture, and corrosive materials are required. They provide long-lasting performance, energy efficiency, and increased safety and visibility.
Polycarbonate Housing LED Tri Proof Light For Indoor Outdoor 100-277VAC IP65 Rated


FAQ:

Q: 1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q: 2. What about the lead time?
A:Sample needs a week, mass production time needs two - three weeks for order quantity below 500pcs..

Q: 3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample cheking is available

Q: 4. How do you ship the goods and how long does it take arrive?
A: We usually ship by DHL, UPS, Fedex or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
