Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Specifications
Place of Origin :
China
Brand Name :
Mingtech
Certification :
Contact PBOC3.0 L1,Contactless PBOC3.0 L1,Contact EMV L1,Contactless EMV L1,CE,FCC,RHOS
Model Number :
IDV-03-A399
Size :
665mm*500mm*1680mm
Extra function add on :
Yes
Voltage :
5V±5%
Supply current :
≦300mA
MOQ :
2
Price :
negotiate
Delivery Time :
15 days<
Supply Ability :
1300 sets per days
Payment Terms :
T/T, PayPal, Western Union, D/P, CommBank.
Description

Mingtech Standard Document Scanner .

Features

Ø USB2.0 full speed

Ø Standard ISO 14443 type A/B

Ø Standard ISO 7816

Ø Shooting regulation of A3/A4

Ø Application area support documents, books, objects, photos, etc

Ø OS support Windows XP/7/8/10


Technical Specifications

ProjectParameters Of Specifications
Power Interface
Power SourceUSB
Supply VoltageDC 5V±5%
Supply Current≦300mA
Cable Length1.8m,Fixed
Communication Interface
ProtocolUSB HID
SpeedUSB Full Speed(12Mbps)
Contact IC Card Interface
Card standardStandard ISO7816 T=0/T=1 Smart Card
Speed9600~115200 bps
Protectionshort-circuit protection and overcurrent protection
EnduranceMinimum 100.000
Contactless IC Card Interface
Card standardISO14443 Type A&B Contactless Smart Card
ProtocolISO14443 /1/2/3/4 T=CL
Frequency13.56MHz±7kHz
Speed106Kbps
SAM
Number of Slots4 Standard SAM-Sized tanks
StandardISO7816 protocol PSAM
Scanner
Pixel of camera

Main camera:10 million pixels;
Face identification camera:2 million pixels(have microphone);

Video formatMJPG,YUY2
Resolution

Main camera:
MJPG:3664×2744,3264×2448,2592×1944,2048×1536,1920×1080,1600×1020,1280×960,1280×720,
1024×768, 800×600,640×480,320×240;
YUY2:3664×2744,3264×2448,2592×1944,2048×1536,1920×1080,1600×1020,
1280×960,1280×720,1024×768,800×600,640×480,320×240;

Face identification camera:
MJPG:1600×1200,1280×960,1024×768,640×480, 320×240;
YUY2:1024×768,640×480,320×240;

Shooting rangeA4(210mm*297mm),A3(297mm*420mm)
Height of ShootA4≈294.62mm,A3≈404.62mm
Intelligent replenishmentMain camera:natural light,LED lighting,touch switch,level 3 brightness adjustable
Others
ExpandTwo USB HUB
BeepSupport
Device VisionSupport
Device SNSupport
OS requirementApply to windows XP , Windows Vista, Window7, etc
Working Environment
Temperature0°C ~ 60°C
Humidity10% ~ 90%
Technical Support
DriverNo driver
APIWindows 32bit SDK
Technical ServiceSupply SDK and Demo
CertificationsContact PBOC3.0 L1,Contactless PBOC3.0 L1,Contact EMV L1,Contactless EMV L1,CE,FCC,RHOS


Applications:

  • E-government
  • Bank and payment
  • Electronic medical
  • cyber security
  • Access control
  • Public transit


Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
Mingtech High Speed Document Scanner , USB2.0 Desktop Receipt Scanner
