ISO7810 Smart Card Reader Module , Magnetic Card Reader Module 3 tracks
ISO7810 Smart Card Reader Module , Magnetic Card Reader Module 3 tracks
Specifications
Brand Name :
Ming tech
Model Number :
MT-RU180
Certification :
Contact PBOC3.0 L1,Contactless PBOC3.0 L1,Contact EMV L1,Contactless EMV L1,CE,FCC,RHOS
Place of Origin :
China
Voltage :
DC5V±0.5V
Interface :
USB,TTL / RS-232
Installation :
External
Card slots :
Single
Application :
Healthcare /e-Government/e-Banking/Transportation/Network security
Weight :
75g
Product name :
Wholesale Portable Black Smart Card Reader Module,ATM Machine Chip Card Reader Manufacturer
Size :
90mm*27mm*28mm
MOQ :
5
Delivery Time :
<15 days
Supply Ability :
2500-3000 sets pers day
Payment Terms :
T/T, PayPal, Western Union, D/P, CommBank.
Packaging Details :
Antistatic package
Description

Magnetic track card reader module (Manual)

Features:

Ø magnetic stripe card reader;

Ø Input wrong alarm& status indicators;

Ø ISO7810/ISO7811 standard;

Ø 170mm Triple-track magnetic stripe card reader.

Ø All 3 tracks can set to 75/300 BPI;

Ø Head reliable for 800,000 time card swipes.

Specifications:

Project Parameters Of Specifications
Scanning function
Direction Dual face swipes, in&out same direction.
Codec. F2F(FM)
Power source

USB cable
Supply current function USB
Serial communication USB
Stack space 1.5mm
Scanning speed 15~120 cm/s
Card thickness 0.2~0.84mm card
Card position matching the head
Size 90mm*27mm*28mm
Weight 75 g
Other
Data input function Manual or Auto
Sensor Card swipe detect.
Shutdown protection Yes(extra cable reserve)
Connection USB2.0 full speed
Switch Power source
Indicators 2 LED lights,power source&status indicators. (IF pass will flash once; failure will flash thrice.)
Cable length

1.5 meters
Drive Non
Environmental.

Running Temp:0℃ - 50℃；

Storage Temp:-30℃ - 70℃；

Humidity:95%

All in one Different standard for different countries;
Advanced Full self-intellectural property;
Almighty Apply to kinds of data collection device demands;
Excellent Help you got a small RIFD reader easily;
Humanist Standard interface for easy development;
Wide use Best choice for small fixed reader;
