Deep Groove ball bearing MR Series-MR115ZZ small vibration Z3V4 ABEC1 ABEC5

Ⅰ. About Miniature ball bearing: Miniature bearings is one kind of deep groove ball bearing, usually we call deep groove ball bearings as small ball bearings when the inner diameter range from 1mm to 8 mm, Metric and imperial sizes miniature bearings are included. These miniature bearings have greatly wide range of applied fields including Skateboard, RC Car, Dental, Fishing Reel,Yoyo, Instrument, Electric Motor, Medical and so on.

Our precision deep groove ball bearings are designed for high precision, low noise, small vibration, high reliability and long life. They are mainly used in various types of electric motors. They are also known as EMQ (Electric Motor Quality) bearings.

Ⅱ. Feature : high precision, high rotating speed, good performance, small clearance, low-noise, competitive price with good quality .

Ⅲ. Application: household appliances, dental drill, toys, electric power tools, electric motors, machine tools, measuring instruments, office machinery, Robot joint, facial beauty rollers, drone etc.

Ⅳ. Specification

• A deep groove ball bearings is the must popular type of rolling-element bearing composed of an outer race ball, an inner race and a bearing cage.and the race dimensions are close to balls dimensions.
• The materials for producing ball bearing are variety including stainless steel,chrome steel and silicon nitride and more with a simpler construction comparing with other ball bearing, deep groove bearings are suitable for large quantity production
• The function of deep groove ball bearings is to reduce rotation friction.those balls between outer race and inner race help avoid two flat surfaces rotating on each other thus to achieve the purpose of lowering down friction coefficient
• Additionally, deep groove ball bearings are primarily used to support radial loads; supports both radial and axial loads is also possible
• Deep groove ball bearings can be used in wide range of applications.

1. Firstly, they can de used in industrial transmission mechanical products.
2. Miniature bearings are widely used in household appliances, toys, electric power tools, car motors and other fields. With optimal design, high reliability heat treatment, precision manufacturing processes and high-grade grease, these products perform better on reliability, vibration and noise levels than standard products making them more suitable for electric motor applications. These products can also be applied to most gearbox applications as well.
3. Thirdly, our bearing are ideal for electrical motor with good quality and excellent performance. Because of their high precision, high rotating speed, high reliability, low friction and low noise, they are widely used in areas of machine tools, measuring instruments, office machinery, household appliances, various types of electric motors, industrial automation control, etc.

Ⅴ. PACKING / Shipping

Normally we packed as below 3 methods, also we can provide package as customer requirements:

1) Tube+outer carton+pallets
2) Single box+outer carton+pallets
3) Tube package+middle box+outer carton+pallets

Ⅵ. MODEL LIST FOR REFERENCE

Product Number	Bore Dia (d)	Outer Dia (D)	Width (B)	Dynamic Load Rating (Cr) (N)	Static Load Rating (Cor) (N)
681	1 mm	3mm	1mm	82	21
691	1 mm	4mm	1.6mm	120	30
681x	1.5 mm	4mm	1.2mm	95	26
681xzz	1.5 mm	4mm	2mm	95	26
691x	1.5 mm	5mm	2mm	144	40
691xzz	1.5 mm	5mm	2.6mm	144	40
601X	1.5 mm	6mm	2.5mm	281	79
601xzz	1.5 mm	6mm	3mm	281	79
682	2 mm	5mm	1.5mm	144	40
682 2RS	2 mm	5mm	2.3mm	144	40
682zz	2 mm	5mm	2.3mm	144	40
MR52	2 mm	5mm	2mm	144	40
MR52 2RS	2 mm	5mm	2.5mm	144	40
MR52zz	2 mm	5mm	2.5mm	144	40
692	2 mm	6mm	2.3mm	281	79
692 2RS	2 mm	6mm	3mm	281	79
692zz	2 mm	6mm	3mm	281	79
MR62	2 mm	6mm	2.5mm	281	79
MR62 2RS	2 mm	6mm	2.5mm	281	79
MR62zz	2 mm	6mm	2.5mm	281	79
MR72	2 mm	7mm	2.5mm	328	103
MR72 2rs	2 mm	7mm	3mm	328	103
MR72zz	2 mm	7mm	3mm	328	103
602	2 mm	7mm	2.8mm	328	103
602 2rs	2 mm	7mm	3.5mm	328	103
602zz	2 mm	7mm	3.5mm	328	103
682x	2.5 mm	6mm	1.8mm	178	59
682x 2RS	2.5 mm	6mm	2.6mm	178	59
682xzz	2.5 mm	6mm	2.6mm	178	59
692x	2.5 mm	7mm	2.5mm	328	103
692x 2RS	2.5 mm	7mm	3.5mm	328	103
692xzz	2.5 mm	7mm	3.5mm	328	103
MR82x	2.5 mm	8mm	2.5mm	474	144
MR82x 2RS	2.5 mm	8mm	2.5mm	474	144
MR82xzz	2.5 mm	8mm	2.5mm	474	144
602x	2.5 mm	8mm	2.8mm	469	142
602x 2RS	2.5 mm	8mm	4mm	469	142
602xzz	2.5 mm	8mm	4mm	469	142
MR63	3 mm	6mm	2mm	178	59
MR63 2RS	3 mm	6mm	2.5mm	178	59
MR63zz	3 mm	6mm	2.5mm	178	59
683	3 mm	7mm	2mm	264	90
683 2RS	3 mm	7mm	3mm	264	90
683zz	3 mm	7mm	3mm	264	90
MR83	3 mm	8mm	2.5mm	336	113
MR83 2RS	3 mm	8mm	3mm	336	113
MR83zz	3 mm	8mm	3mm	336	113
693	3 mm	8mm	3mm	474	144
693 2RS	3 mm	8mm	4mm	474	144
693zz	3 mm	8mm	4mm	474	144
