Mini 3v DC Gear Motor M20 Low Noise 10 mm Diameter With Metal Gearbox
Mini 3v DC Gear Motor M20 Low Noise 10 mm Diameter With Metal Gearbox
Mini 3v DC Gear Motor M20 Low Noise 10 mm Diameter With Metal Gearbox
Mini 3v DC Gear Motor M20 Low Noise 10 mm Diameter With Metal Gearbox
Specifications
Brand Name :
Tronsun Motor
Model Number :
10GFM20
Certification :
RoHS / ISO9001
Place of Origin :
China
MOQ :
100
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
500kpcs/month
Delivery Time :
15-25 working days
Packaging Details :
TBD
Product name :
micro DC gear motor
Voltage Range :
1.5v-6V
Diameter :
10mm
Reduction ratio :
100/1 250/1
Weight :
7g
Application :
Small door lock
Motor :
FF-M20 motor
Shaft :
2.5mm
Description

High Quality low noise 10mm metal gearbox with M20 dc motor mini 3v dc gear motor for door lock

Model No.: 10GFM20

Applications:

Smart electronic door lock

Medical instuments

Toys

Features:

10mm metal gearbox

2.5mm output shaft

0.1-1.5W output power

PMDC brush motor

Encoder available

Threaded shaft available

Varistor inside the motor

Accessories available

2D Drawing:
Mini 3v DC Gear Motor M20 Low Noise 10 mm Diameter With Metal Gearbox
GEARBOX REDUCTION RATIO:

Gearbox Length (mm) Stage Number Reduction Ratio Rated Torque Bearable Maximum Instant Torque
g.cm
9 5 100/1 250/1 300 800


Motor Performance:


MODEL		 REDUCTION RATIO VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
OPERATING RANGE NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT TORQUE CURRENT
V rpm A rpm A g.cm W g.cm A
10GFM20-100-03150 100/1 1.5~3.5 3.0 150 0.055 115 0.18 120 0.14 502 0.58
10GFM20-250-0360 250/1 1.5~3.5 3.0 60 0.055 45 0.18 300 0.14 1252 0.58
10GFM20-100-06240 100/1 2.5~6.0 6.0 240 0.045 192 0.17 130 0.26 665 0.68
10GFM20-250-0695 250/1 2.5~6.0 6.0 95 0.045 78 0.16 300 0.24 1665 0.68


Pls download the PDF document for referrence.

10GFM20.pdf

Product Showcase:

Mini 3v DC Gear Motor M20 Low Noise 10 mm Diameter With Metal Gearbox

FAQ
Q: How to select a suitable motor?
A: If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed life time and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.

Q: Do you have customized service for your standard motors?
A: Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. If you need additional wires/cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.

Q: Do you have individual design service for motors?
A: Yes, we would like to design motors individually for our customers, but it may need some mould charge and design charge.

Q: Can I have samples for testing first?
A: Yes, definitely you can. After confirmed the needed motor specs, we will quote and provide a proforma invoice for samples, once we get the payment, we will get a PASS from our account department to proceed samples accordingly.

Q: Which shipping way is available?
A: DHL, UPS, FedEx, TNT, Sea are available.The other shipping ways are also available, please contact us if you need ship by the other shipping way.

Q: How long is the deliver[Producing] and shipping?
A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.

Q: My package has missing products. What can I do?
A: Please contact our support team and we will confirm your order with the package contents.We apologize for any inconveniences.
