Specifications
Brand Name :
JYS
Model Number :
PD410Y-1
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Unit
Price :
Negotation,CNY, USD
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1200 Units
Delivery Time :
55 working days
Packaging Details :
Naked, Delivered by RORO or Bulk Cargo Ship
Moving type :
Crawler Bulldozer
After-sales service provided :
Online support,Video technical support
Condition :
New
Color :
Yellow,Customized
Engine :
Cummins
Engine model :
Cummins KTA19-C525
Blade type :
Straight Tilt Blade,Semi-U blade
Product name :
Crawler Bulldozer,mini crawler blade dozers for sale
Type :
Crawler Dozer,Hydraulic Bulldozer
Original :
100% China
Name :
Crawler Bulldozer
Warranty :
1year
Gradeability :
30%
Description

High Torque Heavy Equipment Dozer Miniature Bulldozer Dry Type PD410Y-1

The appearance of the Machine is based on optimization design.

◆ High engine power reserve, strong torque output, low fuel consumption, reliable controls.

◆ The technology of the machine adopted advanced Japanese technology.

◆ Hydraulic gear shift transmission for easier gear shift and lower impacts .

◆ 3 elements, single stage and single phase torque convertor features high efficiency and

capacity.

◆ The newly cab for a wide view and ROPS –FOPS Structure for high safety.

◆ Three-stage alarm electronic monitor system effectively monitored the movement of the

machine

◆ Electric fuel feeder for easier fuel feeding.

◆ Centralized lubrication for easier maintenance.

◆Implement Controls are Piloted to minimize operating force. Hydraulic system effects

according to the load feedback to save the cost.

Model PD410Y-1
Engine
Model Cummins KTA19-C525
Type Turbocharged Vertical Four-stroke, PT pump Injection
Flywheel power (kW) 306
Rated speed (r/min) 2000
Air cleaner Dry type, horizontal with pre-cleaned cyclone air cleaner
TRANSMISSION SYSTEM
Torque converter 3-element, single-stage, single phase
Transmission Hand-operated, Hydraulic shift, Planetary gear, multiple disc clutch, forced lubrication by gear pump,
Steering clutch Wet, Multiple disc, Spring loaded, Hand operated with booster and hydraulic released
Steering brake Wet, band brake, operated with hydraulic booster
Final drive Spur gear, One reduction inter planetary gear, splash lubrication
UNDER CARRIAGE
Sprocket Segmented
7 (4 single, 3 double)
Track tension Hydraulic adjusted
Floating seals are used in all track rollers, carrier rollers, sprocket and front idlers
TRAVEL SPEED (km/h) 1st 2nd 3rd
Forward 3.4 6.7 12.2
Reverse 4.2 8.0 14.8
TRACK
Type Sealed and lubricated single grouser or sealed single grouser
Track pitch (mm) 260.35
Track width (mm) 610
Number of track shoes (each side) 40
Length of track on ground (mm) 3425
Ground clearance (mm) 600
Track Gauge (mm) 2260
WORK EQUIPMENT
Blade type Semi U blade
Width×Height (mm) 4130×1590
Length×Width×Height (mm) 7092×4314×3928; 9716X 4314X3928 (with Ripper)
Weight (kg) 49500
