0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators
Specifications
Brand Name :
None
Model Number :
FW08
Certification :
CE, ISO9001: 2000, EPA, SGS/Euro 5
Place of Origin :
Shandong,China
MOQ :
1 UNIT
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 Units/Year
Delivery Time :
5-8 days
Packaging Details :
Nude / Wooden Box
Drive Type :
International Combustion Drive
Bucket Capacity :
0.1~0.5m³
Size :
Small-Scale
Condition :
New
Customized :
Support OEM and ODM
MOQ :
1PCS
Color :
Blue, Yellow, Red, Orange,Green,White
Working Hour :
2000h
Transport Package :
Nude / Wooden Box
Specification :
800 KG
Trademark :
Fullwin machinery
HS Code :
84295212
Production Capacity :
5000 Pices
Description

FREE SHIPPING Mini Small Digger CE/EPA/EURO 5 Compact Mini Excavators

Our excavator is designed to tackle the toughest construction, excavation, and earthmoving tasks with ease. With its advanced features and superior performance, this machine provides operators with everything needed to maximize productivity and efficiency.

One of the key features of our excavator is its powerful hydraulic system. This robust system provides exceptional digging force and speed, giving operators the ability to move large amounts of material quickly and efficiently. Furthermore, the state-of-the-art hydraulic system provides precise control for smooth, efficient operation.

The excavator is powered by a highly efficient engine, which delivers impressive power while maximizing fuel efficiency. The engine is also designed to last, ensuring that the machine will deliver reliable performance for years to come.

Another standout feature of our excavator is its cab. Designed with operator comfort in mind, the cab is spacious and comfortable, maximizing productivity and reducing operator fatigue. The cab also comes with a range of advanced features, including climate control, adjustable seats, and an intuitive control panel.

0.1~0.5m3 Bucket Small Mini Digger CE/EPA/EURO 5 Compact Mini Excavators

Preformance Parameter FW08A
Rated Power 7kw-7.5kw
Bucket Capacity 0.025m³
Bucket Width 300mm
Engine Model Koop192f
Optional Engine Briggs&Stratton
Opeating Weight 800kg
Pump Form Single Gear Pump
Set Working Pressure 14Mpa
Swing Speed 12rpm
Travel Speed 2.2Km/h
Gradeability 30°
Ground Pressure 19Kpa
Max. Digging Force 7.5Kn
Dimensions
Total Width 720-780mm
Total Height 1300mm
Total Length 2430mm
Min.Ground Clearance 80mm
Track Ground Length 1140mm
Track Width 150mm
Working Range
Max.Digging Distance 2450mm
Max.Digging Depth 1200mm
Max.Digging Height 2350mm
Max.Dumping Height 1600mm
Min. Swing Radius 1100mm
Max. upgrade Height of Bulldozer Blade 120mm
Max.Digging Depth of Bulldozer Blade 200mm
