Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof
Specifications
Brand Name :
Tiandi
Model Number :
TDDL-10-03
Certification :
CE
Place of Origin :
China
MOQ :
50 sets
Price :
USD130-150/sets
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
USD120/set
Delivery Time :
25work days
Packaging Details :
Packed in carton boxes ,and then wooden pallets
Motor :
DC 12V 800W
Oil Pump :
0.75cc/r
Oil Port :
G3/8”
Tank Size :
1L
System Pressure :
16Mpa
Mounting Type :
Horizontal
Description

Single Acting Hydraulic Power Pack with Plastic Tank

This Hydraulic Power Unit is to operate single acting cylinders,
DC 12V Hydraulic power unit.
DC12V 0.8Kw motor

0.75cc/r gear pump.
1.5 Litre plastic tank with drain plug.
Hydraulic Power pack complete with suction filter, remote,return oil pipe and air breather.
Mounting: Horizontal Mounting.
Max pressure: 160 bar.
Relief valve: RV2-08. set pressure 180 bar, but adjustable from 50-210 bar as standard for each single acting hydraulic power pack.

Check Valve:CV2-08. Non-return Valve to keep cylinder stay .
Flow Rate: 2.5 l/min.
Relief valve and check valve for all standard power unit
Oil Port size :1/4"BSP
Power Packs suitable for all kinds of single acting Hydraulic cylinders.

Basic Information

Motor

DC 12V 800W 2500RPM

Gear Pump

0.75cc/r

Oil Port

G1/4"

Tank Size

1.5L

System Pressure

16Mpa

Mounting Type

Horizontal

Commercial Terms

Minimum Order Quantity:

50pcs

Price:

USD120.00/PC

Payment Terms:

T/T

Supply Ability:

500pcs per month

Delivery Time:

25 working days after advance payment received

Packaging Details:

Packed in carton boxes ,and then wooden pallets

DC12V Power Pack Drawing:

Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof

Hydraulic Power Pack Assemble Plant:

Horizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor FireproofHorizontal Mounting Portable Mini Hydraulic Power Packs 12V With 0.8Kw Motor Fireproof


Competitive Advantage:

1. TIANDI hydraulic is one of earliest factories of hydraulic packs and units. We have a professional team for raw material purchasing to control the cost. Our works are all well trained and effective. All above these makes our price very competitive.

2. Our export department staff is very professional and effective. They are good at export processing, any problems and questions about products or processing, or paper woks, you can contact and count on them.
