3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge
Specifications
Brand Name :
keda
Model Number :
HD-WH100
Certification :
ISO-9001
Place of Origin :
China
MOQ :
1 Units
Price :
$3,000.00-$32,000.00/ Set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
2 Set/Sets per Month
Delivery Time :
10-30 days
Packaging Details :
Packing Details : In bulk or in Standard container. The spare parts will be in box
Transport Package: :
Container
Specification: :
25.0x6.0x1.0m
Usage :
Salt Mining
Dredging depth :
15 m,10 m,14 m,25 m,12 m
Condition :
New,river
Type :
Bucket Dredger,Bucket Ladder
Draught :
80 cm,100 cm,110 cm,60 cm,10 inch
Dimension(l*w*h) :
Customized
Warranty :
1 Year
After-sales service provided :
Engineers available to service machinery overseas,Field installation,commissioning and training,Video technical support,Field maintenance and repair service
Power type :
Diesel
Application :
sand,River,alluvial mining,Gold Dredging,Iron Extraction / Gold Mining
Color :
Customer's Request,customized,choosed by yourself
Product name :
Gold Dredger Machine,bucket chain dredger,gold and diamond dredger
Applicable industries :
Energy & Mining,Construction works ,Building Material Shops,Manufacturing Plant
Structure :
Dismantle,Dismountable Hull Structure,Easy to dismantle and set up,Portable Hull Structure
Working capacity :
200 M3/hour,60-100m3/h,80-200 M3/hour,80-200m3/hour
Work site :
canal,river
Discharge distance :
1500-2000m,1500m
Water flow :
800-8000 M3/hour,450 m3/h,3200m3/h
Description
keda gold bucket chain dredger dubai River bucket chain gold dredger gold mining trailinng gold bucket chain dredger

Product Description

Bucket chain dredgers have good ability to fit different kinds of geologic structure. With the advantages of stable performance, long working life,low cost, high efficiency and little maintenance, its pontoon adopts the assembled box structure, which is equipped with excavation device, lifting device, large particle filter device, transmission device, transfer device, excavated sediment delivery to the sand transportation ship by the conveyor belt. The process including mining sand separation, stone broken, stone grading, sediment washing separation, heavy metal extraction, dehydration, transportation and so on. bucket chain dredger is suitable for salt mining, gold/diamond mining, hard riverbed exploiting and channel cleanning.

Product Application

1.Sand mining,
2. Gold/diamond mining

3.Salt mining
4.Hard riverbed exploiting
5.River/lake desilting
3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge

HD-BCD100 Bucket Chain Dredger 100m3/h

Bucket chain dredger can be customized according to the requirement of the clients.

Model HD-BCD100
LOA 29m
Hull size(LxWxH) 25.0x6.0x1.0m
Main engine brand Cummins
Main engine power 105kw
Max. dredging depth 20m
Draught 0.7m
Max. capacity 100m3/h
Chain bucket qty. 100pcs
Chain bucket speed 15.2m/min
Chain size 700x100x30mm

3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge

3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge

Maintenance and Support

  1. After delivery we send two experienced engineers who will be to guide installing and train local workers.
  2. Support spare parts are in stock.
  3. We provides a convenient way for you to order parts. You can simply select the parts you need according to your specs and have them delivered directly to your site.
  4. 12 months manufacturing warranty on all new installed component parts.
  5. 12 months warranty on engine.
  6. 12 months warranty on hull and all fabricated parts.
  7. In the event that our customers dredging experience unskilled or mechanical failure or they just need to shoot a minor problem, our engineers are available at customer's services, there are always engineers for installation and training if customers needs.3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge

Our Workshop

3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge

Factory Production Line

3200m3 Bucket Chain Dredger gold mining dredging machine river sand diamond mining dredge

Company Profile

specialized in researching, manufacturing and selling cutter suction dredger, wheel bucket dredger, jet suction dredger, bucket chain dredger, multi-function service work boat ,sand transportation ship etc, which are widely used in sand mining, river dredging, desilting, gold/diamond mining , port construction etc. All the products can be customized according to client's requirement.

We have professional R&D department, CAD drawing design center, quality control department, after-sales service department, operating and purchasing department and product testing center. Our company has more than 200 employees, including 5 professional senior engineers on dredger building and researching, and more than 25 intermediate grade technical personnel. They specialize in designing and building dredgers and sand mining machinery.

In recent years, our dredgers and gold mining equipment have been successfully exported to Malaysia, Pillippines, Indonesia, Bangladesh, India, Brazil, Bolivia, Benin, Egypt, Nigeria, Cango, Liberia, Tanzania, Sultan , Russia ,Ukraine, Iran, Saudi Arabia, Pakistan, and North Korea, etc..
