ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
Specifications
Brand Name :
Sinotruk HOWO
Model Number :
ZZ3257N3647A
Certification :
ISO9001/CCC
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500 UNITS/MONTH
Delivery Time :
35 working days
Packaging Details :
Nude
Dimensions (L x W x H) (mm): :
7934x2496x3386mm
Payload: :
25ton
Wheelbase(mm): :
3225mm+1350mm
Gross Vehicle Weight: :
11290kg
Front/Rear overhang: :
1500/1859mm
Color: :
Optional
Description

ZZ3257N3647A SINOTRUK HOWO 6x4 336hp mining dump truck with 25ton payload

Application:

1. Mature dumper truck chassis, rebuilding dump special device, easy loading and fast unloading.
2. High efficiency, low cost, new technique, low fuel consumption, enduring service life.
3. Easy and safe to load, environmental and sanitary, applicable to collect and remove garbage in the cities, towns and communities.

Competitive Advantage:

1. The price is competitive; we are the direct channel to supply car carrier semi trailer.

2.Powerful engine and reinforced axle

3. All colors are available according to your choice.

4. Fast production period, and quick arrangement of delivery.

5. Professional Sales Team of trucks. Our target is not selling trucks; we help customers choose the best suitable trucks as per customer’s situation.
6. Professional team for spare parts and aftersales services.

7. Technique support and training.

8. Customization service, as per your request, we will customize our production for you

Packing:

Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.We have professional forwarding partners.

Specification:

Howo dump truck basic Made SINOTRUK
Series HOWO
Howo dump Model ZZ3257N3647A
Howo dump Driving Type 6x4
Howo dump Engine Howo dump Engine model WD615.69
Howo dump Engine Type 6-cylinder in-line with water cooling, turbo-charging and intercooling,4-stroke direct injection diesel engine
Howo dump Maximum output 336 hp (247 Kw) at 2200 rpm
Howo dump Displacement 9.726 L
Bore 126 mm
Stroke 130 mm
Compression ratio 29.8 hp/l
Specific fuel consumption 195 g/kWh
Howo dump Transmission Model HW15710(Fuller technology)
speeds 10 speeds
Howo dump Axle Front Axle 9T
Rear Axle 16T
Howo dump Fuel tank Aluminium fuel tank 300 L capacity with locking fuel cap
Howo dump Steering Model ZF power steering, modol ZF8098, hydraulic steering
Howo dump Tyre Radial Tyre 12.00R20
Howo dump Driver's Cab Flat roof cab with bed all steal forward control,2-arm windscreen wiper system with three speed,laminated windscreen, damped adjustable driver's seat, with heating and ventilating system, adjustable steering wheel,air conditioner
Howo dump Dimensions mm Wheel base 3600+1350
Overall dimmensions 8145*2496*3386
Dimension of the rear dump body 5400*2300*1400(17M3)
Howo dump Performance Maximum driving speed (km/h) 75
Maximum gradeability (%) 40
Minimum ground clearance (mm) 314
Minimum turning circle (m) 20
Fuel consumption (l/100 km) 28

ZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional ColorZZ3257N3647A 25 Ton Tipper Truck / Sinotruk Howo Dump Truck Optional Color
