SINOTRUK Euro II 6x4 Prime Mover Truck With HW79 Cabin / HW15710 TRANSMISSION
SINOTRUK Euro II 6x4 Prime Mover Truck With HW79 Cabin / HW15710 TRANSMISSION
SINOTRUK Euro II 6x4 Prime Mover Truck With HW79 Cabin / HW15710 TRANSMISSION
SINOTRUK Euro II 6x4 Prime Mover Truck With HW79 Cabin / HW15710 TRANSMISSION
SINOTRUK Euro II 6x4 Prime Mover Truck With HW79 Cabin / HW15710 TRANSMISSION
SINOTRUK Euro II 6x4 Prime Mover Truck With HW79 Cabin / HW15710 TRANSMISSION
Specifications
Brand Name :
SINOTRUK HOHAN
Model Number :
ZZ4257N3247
Certification :
ISO9001
Place of Origin :
SHANDONG
MOQ :
1 UNIT
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500 units/month
Delivery Time :
30-45 work days
Packaging Details :
Nude
Model :
ZZ4257N3247
Drive Type :
6x4 LHD (RIGHT HAND DRIVE IS OPTIONAL)
Dimension :
6800x2500x3095mm
Displacement (L) :
9.726
Maximum driving speed (km/h) :
90
Gross vehicle weight :
40000kg
Description

SINOTRUK HOHAN 6x4 Euro II tractor truck with HW79 cabin and HW15710 TRANSMISSION

Description:

The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.The engine adopt 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection.Adopting full hydraulic transmission, it can bring the power of engine into full play amply.Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.Rich experience and well after-sale service.

Packing:

Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.We have professional forwarding partners.

Competitive Advantage:

1. The best quality standard guaranteed

2. Product upgrading and expansion of species
3. Good quality with competitive prices.

5. The price is competitive.

6. Excellent and high-quality control
7. Long lasting working life time.

Model ZZ4257N3247
Drive Type 6x4 LHD (RIGHT HAND DRIVE IS OPTIONAL)
Cab Type Long Cabin
Equipment two sleepers with Air Condition
Weight Kerb mass(kg) 8800
GVW(kg) 40000
Dimensions Max. L*W*H(mm) 6800x2500x3095mm
Front/Rear overhang 1415/785
Wheel base(mm) 3225+1350
Track width(mm) 1830/1830
Performance Max. speed (km/h) 90
Max. gradeability(%) 30
Approach/Departure angel 20/40
Engine Brand SINOTRUK
Model WD615.69
Power (kw/hp) 336HP(247KW)
Max torque
Displacement (L) 9.726
Emission Standards Euro II
Transmission Brand SINOTRUK
Model HW15710
Gear Shift 10-forward & 2-reverse speeds
Clutch Type Single plate,diaphragm spring
Diameter (mm) 430
Action hydraulically operating with air assistance
Brakes Type Drum
Service Brake With dual-circuit compressed air brake
Park Brake Power spring brake acting on rear wheel
Auxiliary Brake WEVB
ABS With ABS
Steering Brand ZF TECHNOLOGY
Type ZF8098 hydraulic steering with power assistance
Chassis Type U-profile parallel ladder frame and reinforced subframe
Dimensions (mm) 300x80x8
Suspension Front 9 semi-elliptic leaf springs
Rear 12 leaf semi-elliptic springs
Axles Brand SINO HOWO
Front HF7 7T front axle, drum brake
Rear MCY13Q: 13 ton strengthened axle,
double reduction driving axle
Ratio 3.08
Option 4.11/3.70
Tire Type 295/80R22.5 TUBELESS TIRE
Option 12.00R20 RADIAL TIRE
Fuel tank Tank capacity(L) 400
Material Aluminum alloy/Iron
Electrics Type 24V
Starter 5.58kw(24)
Generator 2.0kw(28V 70A)
Battery 2x135Ah
