GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine
Specifications
Brand Name :
ROADY
Model Number :
QSB3.9-C125
Certification :
CE ISO CU-TR
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500 units/month
Delivery Time :
30-45 Work days
Packaging Details :
Nude.
Max. Paving Thickness: :
200mm
Dimension(Lx W x H)(unloaded)(mm) :
5500mmx2050mmx3415m
Production Capacity: :
150t
Max. paving width: :
4.5m
Leveling Tolerance(wave): :
2mm/3m
Weight: :
10.5t
Description

GYA4200 150t Road Constructions of Asphalt Paver with 4.5m paving width

Packing:

Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.

Competitive Advantage:

1. All colors are available according to your choice.
2. Fast production period, and quick arrangement of delivery.
3. Professional Sales Team of trucks. Our target is not selling trucks; we help customers choose the best suitable trucks as per customer’s situation.

4.Warranty: one year

5. Production time: within 35 working days

6. Logistic team, can cargo your truck fast and safety.

Item unite GYA4200
Main technical parameters Travel model Crawler
basic paving width m 1.8(standard 2.0)
Max. paving width m 4.2(Max.4.5)
Max. paving thickness mm 200
working speed m/min 0-20
Running speed km/h 0-4.5
Theoretical productivity t/h 150
Hopper capacity t 10
Grade ability % ≥20
Leveling Tolerance(wave) mm/3m 2
Transverse wave Error % ±0.02
Arch degree adjusting range % -1~+3
Engine Manufacturer Dongfeng Cummins
Model QSB3.9-C125
Fuel tank capacity L 115
Rated power kW 93
Rated speed rpm 2200
Electric system V 24
Emission standard Stage Ⅲ
Crawler Area on ground mm*mm 2425*260
Crawlers width mm 1284
Track width mm 260
Screed system Screed model Hydraulic telescopic
Hydraulic telescopic range m 1.8~3.6
Compaction type Single tamping
Tamping frequency HZ 25
Vibrating amplitude mm 5
Vibrating frequency HZ /
Heating type Propane gas heating
Dimension and weight Overall length mm 5500
Overall width(basic segment) mm 2050
Overall height(with Cab) mm 3415
Transportation height mm 2765
Overall mass t 10.5

GYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver MachineGYA4200 150 Ton Asphalt Paving Equipment , Road Construction Paver Machine

Product Description

Road Constructions of GYA4200 Asphalt Paver uses for municipal roads, indoor works, small-area projects and so on.

Microelectronic control enables independent left-right driving of scraper transport and spiral feeding, automatic feeding anduniformmaterials in front of the screed plate; it also provides fastresponse speed and high leveling precisionfor the leveling system. The left and right crawlers are equipped with independent hydraulic drives which enable non-slipping steering and pivot steering.
