Specifications
Brand Name :
XCMG
Model Number :
XE150D
Certification :
CCC ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
500 sets per month
Delivery Time :
30-45 work days
Packaging Details :
Nude
Fuel Type: :
Diesel
Model Number: :
XE150D
Maximum Digging Depth: :
5515mm
Machine Weight: :
14600kg
Emission Standard :
Euro 2
Engine: :
Yanmar Engine
Description

XCMG New Model Road Construction Diesel Excavator XE150D With Yanmar Engine

Product Description

1, The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.
2, The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.
3, The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
4, The advanced structure and hinge points on the digging end and the industrys largest rotating angle of the bucket ensure strong soil holding capacity.

specification

Unit Parameters
Model Operating weight Kg 14400
Bucket capacity 0.52~0.61
Engine model / CUMMINS 4BTAA3.9
Main Gradient capability ° ≤35°
performance Ground pressure KPa 38
Digging capacity of bucket KN 85
Digging capacity of bucket rod KN 65
Max traction force KN 135
Main pump / Two plunger pumps
Hydraulic Rated flow of main pump L/min 2x120
system Pressure of main sadety valve MPa 31.4/34.3
Pressure of traveling system MPa 34.3
Pressure of swing system MPa 25
Pressure of pilot system MPa 3.9
Fuel tank capacity L 250
Oil volume Hydraulic tank capacity L 130
Engine oil volume L 14
A Total length mm 7801
B Total width mm 2590
C Total height mm 2880
Overall D Width of rotary table mm 2512
Dimension E Length of track mm 3660
F Total width of chassis mm 2590
G Width of track mm 600
H Wheelbase of track mm 2910
I Track gauge mm 1990
J Counterweight ground clearance mm 964
K Min ground clearance mm 478
L Min tail swing radius mm 2325
A Max.digging height mm 8641
B Max unloading height mm 6181
Working C Max digging depth mm 5538
Radius feet digging bepth under ground mm 5287
E Max vertical digging bepth mm 4727
F Max digging radius mm 8296
G Max swing radius mm 2335
Stabdard Boom length mm 4600
Configuration Length of bucket rod mm 2510
Bucket capacity 0.61
Optional Bucket capacity 0.52 Rock bucket

Product Description

XCMG Road Construction Machinery Diesel Excavator XE150D With Yanmar Engine

Packaging & Shipping

XCMG Road Construction Machinery Diesel Excavator XE150D With Yanmar Engine

Our Services

XCMG Road Construction Machinery Diesel Excavator XE150D With Yanmar Engine

FAQ

XCMG Road Construction Machinery Diesel Excavator XE150D With Yanmar Engine

Packing

Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.We have professional forwarding partners.

Our customer all over the world

African countries:

Congo, Tanzania, Djibouti, Angola, Chad, Algeria, Sudan, Libya, Eritrea, Uganda, Rwanda, Burundi and the Seychelles. Mauritania, Western Sahara, Senegal, Gambia, Mali, Burkina Faso, Guinea, Guinea-Bissau, Cape Verde, Sierra Leone, Liberia, Côte d'Ivoire, Ghana, Togo, Benin, Niger, Nigeria , Namibia, Cameroon, Equatorial Guinea, Ethiopia, Kenya , Gabon and Zambia, Angola, Zimbabwe, Malawi, Mozambique, Botswana, and so on.

South America:
Colombia, Venezuela, Guyana, French Guiana, Suriname, Ecuador, Peru, Bolivia, Brazil, Chile, Argentina, Uruguay, Paraguay, Guatemala, Belize, El Salvador, Honduras, Nicaragua, Costa Rica, Panama, Antigua and Barbuda

South Pacific:
Papua New Guinea, Northern Mariana Islands, French Polynesia, Fiji, Guam, Heard and McDonald Islands, Kiribati, Cocos Islands, Cook Islands, Republic of the Marshall Islands, American Samoa, Microrony West Asia, Nauru, Niue, Norfolk Island, Palau, Pitcairn Islands, Samoa, Christmas Island, Solomon Islands, Tonga, Tuvalu, Tokelau, Wallis and Futuna, Vanuatu, New Caledonia.

Asia countries:
North Korea, Mongolia, including Vietnam, Laos, Cambodia, Myanmar, Thailand, Malaysia, Singapore, Indonesia, Philippines, Brunei, Sri Lanka, Maldives, Pakistan, India, Bangladesh, Nepal, Bhutan, Afghanistan, Iran, Azerbaijan, Armenia, Georgia, Turkey, Cyprus, Syria, Lebanon, Palestine, Jordan, Iraq, Kuwait, Saudi Arabia, Yemen, Oman, United Arab Emirates, Qatar, Bahrain, Turkmenistan, Uzbekistan, Kyrgyzstan, Tajikistan, Kazakhstan.
