Specifications
Brand Name :
SINOTRUK HOWO
Model Number :
ZZ3257N3447A
Certification :
ISO9001
Place of Origin :
Shandong，China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
500sets per month
Delivery Time :
30-45days
Packaging Details :
packed in nude
Model :
ZZ3257N3447A HOWO Dump Truck
Emission Standard :
Euro 2
Engine Model :
WD615.69
Horsepower :
336hp
Cabin :
HW76,Single Bunk,AC(Option:Right Hand Driving)
Transmission :
SINOTRUK HW19710 Transmission ,10 Forward And 2 Reverse
Description

SINOTRUK HOWO 336hp 6X4 drive dump truck for sale

SINOTRUK HOWO 6x4 DUMP TRUCK SPECIFICATIONS

Body

 Carriage Internal Dimensions(mm) 5200x2300x1400
Cubage (m3) 16.75
Steel thickness of Carriage(mm) Floor:8mm/Side:6mm
Steel Q235
Hydraulic Lift of Carriage Middle Lift

Weight in kg

 Kerb weight (Kg) 12270
Gross vehicle weight (Kg) 30000

Dimension(mm)

Dimensions(mm)

 Length(mm) 8045
Width(mm) 2550
Height(mm) 3450
Wheel base (mm) 3400+1350

Performance

 Maximum driving speed (km/h) 75
Fuel consumption (1/100 km) 38

Cab

 Model SINOTRUK HW76 Lengthen cab
HW76 cab, single sleeping, with air-condition), all-steel forward control, 70° hydraulically tiltable to the front, 2-arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.

Engine

 Model WD615.69(Euro 2)
Type 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
Horsepower 336
Maximum output Kw/r/min 247/2200
Maximum torque N.m/r/min 1350/1300-1600
Bore x Stroke 126x130mm
Valve 2
Displacement 9.726L
Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80℃ opening begin, Rigid fan
Transmission SINOTRUK HW19710 transmission ,10 forward and 2 reverse

Clutch

 SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance

Steering

 ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)

Front Axle

 SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.

Rear Axles

 SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.73;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.

Brake System

Service brake:dual circuit compressed air brake

Parking brake (emergency brake):spring energy,compressed air operating on rear wheels

Wheels & Tyres

Rims:10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire.

(Front tyre TR688 back tyre TR691 Triangle brand)

Electrics

Operating voltage:24V,negative grounded

24V,7.5KW.Starter:24V,7.5 Kw

28V,1500W.Alternator:3-phase,28V,1500 W

2x12V,165Ah.Batteries:2x12 V,165 Ah

horn,headlamps,fog lights,brake lights,indicators and reverse light
Oil Tank Square type-300L Aluminum alloy fuel tank

(All pictures are for reference only.)

Euro 2 6X4 Drive Heavy Duty Dump Truck SINOTRUK HOWO 336 Horsepower

Euro 2 6X4 Drive Heavy Duty Dump Truck SINOTRUK HOWO 336 Horsepower

Euro 2 6X4 Drive Heavy Duty Dump Truck SINOTRUK HOWO 336 HorsepowerEuro 2 6X4 Drive Heavy Duty Dump Truck SINOTRUK HOWO 336 Horsepower

Description:

HOWO brand. now is the hot sales brand of overseas market, the popular model is with 18m³, 20m³, 30m³ dumper bucket capacity using in road project solution, mining site , and other urban construction etc.SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.73;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.

Applications:

It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.

Competitive Advantage:

1. Warranty: one year

2. Production time: within 35 working days

3. Shipping: we have logistic team, can cargo your truck fast and safety.

4. Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to the special needs of the commodity.
