Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
Specifications
Brand Name :
JBC
Model Number :
JBC-26
Certification :
ISO/CCC
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
500 units/month
Delivery Time :
30-45 work days
Packaging Details :
Nude
Power(W): :
78 KW
Dimension(L*W*H): :
7800*2750*4100 mm
Emission Standard: :
Euro II
Max. Travel Speed: :
30 km/h
Engine Model: :
Yuchai 4102
Weight: :
6500 KG
Description

4x4 Euro II JBC-26 2.6 M3 Self-Feedding Concrete Mixers With Yuchai 4102 Engine

Description:

The mixer size is small, which is suitable for limited place and widely used in new rural construction, urban construction, tunnel, airport, seaport, high-speed rail site, remote areas where there are no electric power, middle projects, farmer's houses, building, country road, irrigation, reservoir, mine, rural bridges, high-way road etc, which characterized in saving labors, high efficiency concrete output.

1.JBC-26 Self Loading Concrete Mixer Truck is a integration of mixer and wheel loader. It can automatically load, measure, mix and discharge concrete mixture.

2. Cab and mixer drum can be integrated , rotate 270°together, which makes forward-reverse universal. Rolling drum can also be lifted up 20°to make discharge concrete easier. Rotational speed of mixer drum is up to 20 rpm that improves working efficiency by 30%.

3. It makes mixer truck more safe and stable by using wet brake of front axle, air brake, double brake system and double front tires.

4. Equipped with change-over switch, the centrifugal water pump can suck water into water tank and mixer drum respectively.

5. 16mm thick high-strength steel plate, enhances load capacity and stability of the mixer truck.

Packing:

Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.We have professional forwarding partners.

Competitive Advantage:

1.Full hydraulic transmission, can bring the power of engine into full play amply.

2.Adjust the output torque automatically, can achieve continuously variable transmission.
3. Small turning radius,convenient to work in confined places.

4. Single-line air-assisted brake system,safe and reliable.1.The best quality standard guaranteed
2.Product upgrading and expansion of species
3.Good quality with competitive prices.

5. The price is competitive.

6.Excellent and high-quality control
7.Long lasting working life time.

Model

JBC-26

Mixing Drum

Mixing Capacity

2.6 m³

Geometrical Capacity

3.6 m³

Concrete Output

2.6m³/batch, 10.4m³/h

Drum Rotating Speed

13 rpm

Drum Rotating Angle

270°

Engine

Model

YUCHAI 4102

Type

In-line, 4-Cylinder, 4-Stroke, Turbo Charged, Water Cooled

Rated Power

78 KW (106HP) @ 2400 rpm

Emission Standard

Euro II

Loading Bucket & Discharge Chute

Loading Bucket Capacity

0.6 m³

Loading Times to Full Drum

5 Times

Discharge chute

2 Sets

With Extender

Rotation angle range 90°, manual shank

Water System

Max. Water suction Volume

250 L/min. (Self-priming electronic water pump)

Water tank Volume

2x250 L

Mixer

Max. Travel Speed

30 km/h

Gradeability

40°

Min. Turning Radius

5300 mm

Operating Weight

6500 kg

Max. Load

6200 kg

Max. Gross Weight

12700 kg

Overall Dimension (L×W×H)

7800*2750*4100 mm

Fuel Tank Volume

75 L

Total Hydraulic System Capacity

75 L

Oil Tank Volume

16 L

Euro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 EngineEuro II JBC-26 2.6 M3 Concrete Construction Equipment With Yuchai 4102 Engine
