Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
Specifications
Brand Name :
XCMG
Model Number :
XE305D
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10000 Unit/Units per Year
Delivery Time :
30 days
Packaging Details :
Nude
Bucket capacity :
1.2~1.6m³
Rated Speed :
5.2/3.1 km/h
Maximum Digging Depth :
7200mm
Operating Weight :
30ton
Maximum Digging Height :
10146mm
Max Digging Radius :
10665mm
After-sales Service Provided :
Overseas service center available
Description

Yellow XCMG XE305D China Made 30 ton Crawler Excavator Hydraulic 1.4m³ Bucket

Product description

1,The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.
2,The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.
3,The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
4,The advanced structure and hinge points on the digging end and the industry’s largest rotating angle of the bucket ensure strong soil holding capacity.

Product parameter

Model Unit 305D
Operating Weight kg 30800
Bucket Capacity m³ 1.2-1.6
Engine Model Engine QSB7
Rated power/swing speed kW/ r/min 169/2050
Torque/swing speed N.m 895/1250
Displacement L 6.7
Travel speed(H/L) km/h 5.2/3.1
Grade ability % 70
Rotary speed r/min 9.8
Ground pressure kPa 60
Bucket digging force kN 198
Arm digging force kN 138
Main pump -- K5V140DTP
Rated flow L/min 2×140
Main safety valve pressure MPa 34.3/37
Pressure of pilot system MPa 3.9
Fuel tank capacity L 520
Hydraulic tank capacity L 270
Engine oil capacity L 20
Total length mm 10645
Total width mm 3190
Total height mm 3410
Width of platform mm 3050
Length of crawler mm 4944
Total width of chassis mm 3190
Width of crawler mm 600
Wheel base of crawler mm 4028
Track gauge mm 2590
Ground clearance of counterweight mm 1198
Min. ground clearance mm 538
Min. rear-end swing radius mm 3200
Max. digging height mm 10146
Max. dumping height mm 7180
Max. digging depth mm 7200
Max. digging depth at the range of level 8 feet mm 7000
Max. vertical digging depth mm 5190
Max. digging radius mm 10665
Min. swing radius mm 3076

Product picture

Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket

Name: Hydraulic system

The internationally renowned hydraulic system is used to upgrade the hydraulic pipeline at the same time, which reduces the oil return pressure loss, improves the composite operation of the front end working device, improves the handling performance of the whole machine, and comprehensively improves the working efficiency, coordination and stability of the whole machine.

Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket

Name: Chasis

The standard extended and reinforced chassis system provides better mine stability and higher reliability. The four-wheeled belt adopts a reinforced four-wheel belt to ensure the service life of mines and other harsh conditions.

Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket

Name: Cabin

The seat designed on the basis of ergonomics concept considerably enhances the comfortable sensation. The suspension bag can adjust the height of seat according to the weight adjustment,making the operation more comfort.

Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket

Name: Filter

By use of an up-to-date fuel filter,the filtration performance has been improved,the oil-taking quality guaranteed and the operation reliability of engine under severe operation conditions enhanced.

Yellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ BucketYellow XCMG XE305D 30 Ton Crawler Excavator Hydraulic 1.4m³ Bucket
