Fuel tank truck specification | |
Truck brand | 20-25cbm Fuel Tanker Truck |
Driving type | Left hand drive/Right Hand Drive |
truck fuel tank size(L*W*H) | 9950*2550*3750(mm) |
Tank capacity(L) | 20000-25000L |
Approaching angle/Departure angle(°) | 16/12(°) |
F/R track base(mm) | 1205/3485 (mm) |
Curb weight(kg) | 11360(Kg) |
Max speed(km/h | 90 |
Tank specification | |
Tank volume | 20000L-25000L truck fuel tanks |
Tank Material | carbon steel/Stainless steel/aluminum alloy |
Engine(Steyr technology, made in China) | |
Model | WD10.300-22/WP10.340E22/WP10.380E22,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection |
Fuel type | Diesel |
Horse Power, max(kw/rpm) | 300/340/380HP |
Emission | EURO 2 |
Fuel tanker capacity (L) | 400 |
Transmission | |
Model | HW19710,10 forwards and 2 reverse |
Brake system | |
Service brake | Dual circuit compressed air brake |
Parking brake | spring energy, compressed air operating on rear wheels |
Auxiliary brake | Engine exhaust brake |
Steering system | |
Model | ZF8098 |
Other specification | |
Front axle | HF9 |
Rear axle | HC16 |
Color | Optional |
Tire | 11.00-20 / 12.00-20/ 295/80R22.5 |
Tire quantity | 11 |
Electrical system | |
Battery | 2X12V/165Ah |
Alternator | 28V-1500kw |
Starter | 7.5Kw/24V |
