Specifications
Brand Name :
YK
Model Number :
VSI-8518
Certification :
iso9001
Place of Origin :
china henan
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100 Set/Sets per Month
Delivery Time :
Within 30 days after receipt of the equipment's deposit
Packaging Details :
standard container, spare parts will be packed in wooden cases
Warranty :
1 Year
After-sales service provided :
Engineers available to service machinery overseas,Video technical support,Online support,Field maintenance and repair service,Field installation
Motor type :
AC Motor
Application :
Mining,construction,Quarry,coal,ore/quarry
Type :
Impact Crusher
Condition :
New
Capacity :
100-260 t/h
Double Motor Power :
4P 180kw
Weight :
14.5 t
Power supply :
380V 50HZ
Overall dimension :
4140×2280×2425
Description

Vsi Vertical Shaft Impact Crusher Machine, Hard Rock Gold Mining Equipment, Industrial Rock Crusher


Working Principle of Vertical Shaft Impact Crusher
Material falls into the highs peed turning impellers from the top of machine and crushes with the material distributed around the impeller under the effect of high speed centrifugal force. After the impact with each other, the material is crushed between impeller and cabinet and is discharged from the bottom. It can cycle many times with the close circuit and the sieve device will control the granularity of finished products.


Introduction of Vertical Shaft Impact Crusher

Hard Rock Gold Mining Equipment Rock Crushing Equipment With Ac Motor
Vertical shaft impact crusher is also named Sand making machine which features is a unique combination of rotor design, wear material and crushing equipment design. This combination has proved revolutionary in improving capacity, gaining superior product shape quality and in reducing operating and wear costs. Impact crusher is a high-efficient rock crushing equipment with home and international leading level. The machine is developed by introducing the crushing theory and technology from Barmag Company of America and combining the actual situation of sand making. It is widely used for crushing of hard and crispy materials, such as rocks, grinding materials, refractory materials, cement clinkers, quartzite, iron ores and concrete aggregates. It is especially suitable for the sand and sandstone making for construction and road paving. It is more suitable for crushing mid-hardness materials and high-hardness materials. It is more suitable for crushing mid-hardness materials and high-hardness materials and Its product is cubic, and the density of piling up is high and the iron pollution is low. More environment protect with the working noise less than 75 decibels and little dust pollution.

Hard Rock Gold Mining Equipment Rock Crushing Equipment With Ac Motor
Features of Vertical Shaft Impact Crusher
1. Excellent performance and high final fineness
2. Safe and user-friendly
3. Smooth and quiet operation
4. Minimum maintenance
5. Heavy duty design
6. Long service life
7. Standard replacement parts
8. Cost effective
9. Cubically shaped product
10. High productivity

Hard Rock Gold Mining Equipment Rock Crushing Equipment With Ac Motor
Technical Parameter of Vertical Shaft Impact Crusher

ModelVSI-7611VSI-8518VSI-9526VSI-1140
Capacity
(t/h)
Feed both
at center
and sides
120-180200-260300-380450-520
Feed at
center
60-90100-130150-190225-260
Max.feeding
size(mm)
Soft
material
35404550
Hard
material
30354045
Rotation
speed
(r/min)
1700-18901520-16901360-15101180-1310
Double Motor
power(kw)
4P 1104P 1804P 2644P 400
Overall dimension
(L×W×H)(mm)
3700×2150×21004140×2280×24254560×2447×27785000×2700×3300
Total weight(t)11.814.517.825.6
Power supply380V 50HZ


Hard Rock Gold Mining Equipment Rock Crushing Equipment With Ac Motor
