Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
Specifications
Brand Name :
YK
Model Number :
DME2055
Certification :
ISO9001
Place of Origin :
HENAN XINXIANG
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100 Set/Sets per Month
Delivery Time :
Within 30 days after receipt of the equipment's deposit
Packaging Details :
standard container, spare parts will be packed in wooden cases
Type :
Trommel Screen
Condition :
New
Warranty :
1 Year
After-sales service provided :
Engineers available to service machinery overseas,Video technical support,Online support,Field installation,commissioning and training
Capacity (t/h) :
120-250
Power (kw) :
30
Dimension (L×W×H)(mm) :
7500*2500*4000
Weight (t) :
8.6
Description

Portable Gold Trommel Screen Equipment No Pollution Easy Maintenance For Sand Stone, Rotary Trommel Screening System

Detailed Product Description

Trommel screen is a special screening equipment developed by our company for the power plant, coking plant, building material, metallurgy, chemical industry, mine and other industries. It overcomes the screen clogging problem of circular vibrating sieve and linear sieve in sieving wet materials. It improves the screening system reliability and obtains lots of praises from users.

Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001

Working Principle

This series of trommel screen is the traditional screening equipment, composed by the octagonal drum, frame, funnel, reducer, and motor. Crushed stone comes into the drum sieve, and the drum sieve rotating centrifugal force through different mesh screen and the jig working to sieve the material. After the filter, different specifications stone materials fall down the belt conveyor to the finished material yard. Its structure is simple and reliable, smooth operation, with good sealing, no pollution, lower noise, changing the net easy, fine classification, sorting ratio, sorting accuracy, low failure, easy maintenance, especially for sand stone classification.

Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001

Technical Parameters

Model Capacity (t/h) Power (kw) Drum Diameter (mm) Drum Length (mm) Screen Size (mm) Dimension (mm) Weight (t)
DME0510 1-10 1.5 500 1000 ＜3-10 1800*1020*1500 1.0
DME1015 5-20 4.0 1000 1500 3000*1400*2145 2.2
DME1020 10-40 5.0 1000 2000 3460*1400*2145 2.8
DME1225 20-60 7.5 1200 2500 4146*1600*2680 4.2
DME1530 30-90 11 1200 3000 4460*1900*2820 5.1
DME1545 50-120 15 1500 4500 5960*1900*3080 6.0
DME1848 70-180 22 1800 4800 6500*2300*4000 7.0
DME1860 80-200 22 1800 6000 8000*2300*4000 7.5
DME2055 120-250 30 2000 5500 7500*2500*4000 8.6

Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001

Portable Gold Rock Screening Equipment 120 - 250t/H Capacity ISO9001
