Msw Municipal Solids Waste Rotary Dryer Price Reasonable Price Intelligent Control

Dryer is widely used for drying slag limestone, coal powder, slag, clay, etc. Dryer can also be used in building materials, metallurgy, chemical and cement industry. Dryer mainly consists of dryer body, raw material feeding plate, driving and supporting device, seal ring, etc. Dryer can be generally divided into four types, they are: rotary dryer, triple-drum dryer, indirect heat transfer dryer, vertical dryer. Different kind of dryer has its own characters and advantages, the specific choice of a special dryer depends on different elements.

1. “Triple Level Drying Core®”,use rotary harrow and auto down and convection unique key patented technology.
2. “Mechanical Material Guiding”technology, the material can move forward or back under the guiding system.
3. Exclusive patented technology:Triple Pass Multi-level, the main structure is consists of three different metal steel cylinder with different diameter, it can get a bigger evapor ation area, and drying faster,
4. “Low-Temperature Larger Air Flow”drying technology, the wet material can get a larger and fast evaporation performanc e under a larger Low-Temperature and air flow.
5. “Auto-Reciprocating MSW Municipal Solid Waste ing Back ”technology.based on this the wet and the dry material can get a fully mixture and rolling in the meantime,and separated into scattered condition.
6. “Pros And Cons Material Spreading System”,through pros and cons material system, the materials can make pros and cons rolling movements,forming many material falls in the drum,so all material can fully spreaded in side the drum which fully contact with the hot air.in another words, there’s no dead spots for the material in side the drum.
7. “Negative pressure”working condition, clean work s ite and operating reliably.

Msw Municipal Solids Waste Rotary DryerTechnical Parameter

1. Model	Cylinder diameter (mm)	Cylinder length (mm)	Cylinder volume (m3)	Cylinder rotary speed (r/min)	Power (kW)	Weight (t)
   0.6×5.8	600	5800	1.7	1-8	3	2.9
   0.8×8	800	8000	4	1-8	4	3.5
   1×10	1000	10000	7.9	1-8	5.5	6.8
   1.2×5.8	1200	5800	6.8	1-6	5.5	6.7
   1.2×8	1200	8000	9	1-6	5.5	8.5
   1.2×10	1200	10000	11	1-6	7.5	10.7
   1.2×11.8	1200	11800	13	1-6	7.5	12.3
   1.5×8	1500	8000	14	1-5	11	14.8
   1.5×10	1500	10000	17.7	1-5	11	16
   1.5×11.8	1500	11800	21	1-5	15	17.5
   1.5×15	1500	15000	26.5	1-5	15	19.2
   1.8×10	1800	10000	25.5	1-5	15	18.1
   1.8×11.8	1800	11800	30	1-5	18.5	20.7
   1.8×15	1800	15000	38	1-5	18.5	26.3
   1.8×18	1800	18000	45.8	1-5	22	31.2
   2×11.8	2000	11800	37	1-4	18.5	28.2
   2×15	2000	15000	47	1-4	22	33.2
   2×18	2000	18000	56.5	1-4	22	39.7
   2×20	2000	20000	62.8	1-4	22	44.9
   2.2×11.8	2200	11800	44.8	1-4	22	30.5
   2.2×15	2200	15000	53	1-4	30	36.2
   2.2×18	2200	18000	68	1-4	30	43.3
   2.2×20	2200	20000	76	1-4	30	48.8
   2.4×15	2400	15000	68	1-4	30	43.7
   2.4×18	2400	18000	81	1-4	37	53
   2.4×20	2400	20000	91	1-4	37	60.5
   2.4×23.6	2400	23600	109	1-4	45	69.8
   2.8×18	2800	18000	111	1-3	45	62
   2.8×20	2800	20000	123	1-3	55	65
   2.8×23.6	2800	23600	148	1-3	55	70
   2.8×28	2800	28000	172	1-3	75	75
   3×20	3000	20000	14	1-3	55	75
   3×23.6	3000	23600	170	1-3	75	85
   3×28	3000	28000	198	1-3	90	91
   3.2×23.6	3200	23600	193	1-3	90	112
   3.2×32	3200	32000	257	1-3	110	129
   3.6×36	3600	36000	366	1-3	132	164
   3.8×36	3800	36000	408	1-3	160	187
   4×36	4000	36000	452	1-3	160	195
