2 Tph Ball Mill Cement Ball Mill ,CE Approved 900*1800 Mill Price
2 Tph Ball Mill Cement Ball Mill ,CE Approved 900*1800 Mill Price
2 Tph Ball Mill Cement Ball Mill ,CE Approved 900*1800 Mill Price
2 Tph Ball Mill Cement Ball Mill ,CE Approved 900*1800 Mill Price
Specifications
Brand Name :
Zoneding
Model Number :
900×1800
Certification :
ISO9001:2008,CE,IQNet
Place of Origin :
China
MOQ :
1set
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 sets/quarter
Delivery Time :
15-20 days
Packaging Details :
Container
Product Name :
Coal Mill in Cement Plant
Capacity :
8.5-60t/h
Weight :
65t
Operating training :
provide
Application :
cement plant
Rotating speed :
21r/min
Weight of ball :
30t
Feeding size :
≤25mm
Discharging Size :
0.074-0.4mm
Condition :
New
Description

2 Tph Ball Mill High Energi Ball Mill ,CE Approved 900*1800 Mill Price
Introduction of Coal Mill
Ball Mill is mainly used to grind materials in mineral, cement , refractory, chemical industry, etc. Ball Mill has dry and wet ways. When wet ball mill works,certain water and other liquid will be added into materials to increase flowability of materials, so the capacity is increased.When dry ball mill works, capacity is affected because material flowability is reduced, so absorbing wind device is needed on the outlet of ball mill, and then negative pressure is formed in the ball mill to increase flowability of material, so the capacity is increased.
Features of Coal Mill
1. High capacity, low cost, competitive price.
2. Simple structure, convenient installation and adjustment.
3. Wear-resistant parts, especially the lining plates.
4. Suitable for many kinds of l material, and continuous operation.
5. Big crushing ratio, uniform end product size and easy to adjust fineness of final products.
Technical Data:

Model

Rotating speed

(r/min)

Weight

of ball

(t)

Feeding size

(mm)

 Discharging size (mm)

Capacity

(t/h)

Power

(Kw)

Weight

(t)
900×1800 38 1.5 ≤20 0.075-0.89 0.65-2 18.5 3.6
900×2100 38 1.3-1.4 ≤15 0.075-0.83 0.7-3.5 18.5 3.9
900×3000 38 2.7 ≤20 0.075-0.89 1.1-3.5 22 4.5
1200×2400 32 3.8 ≤25 0.075-0.6 1.5-4.8 30 11.5
1200×2800 32 3.3-3.5 ≤25 0.075-0.6 2-6 30 13
1200×4500 32 7 ≤25 0.074-0.4 1.6-5.8 45 13.8
1500×3000 27 8 ≤25 0.074-0.4 2-5 75 17
1500×3500 27 6.75-6.4 ≤25 0.075-0.4 3-7 75 17.5
1500×4500 27 14 ≤25 0.074-0.4 3.5-12 110 21
1500×5700 27 15 ≤25 0.074-0.4 3.5-8 115 24.7
1830×3000 24 18 ≤25 0.074-0.4 4-10 130 28
1830×3600 24 10.6-11.35 ≤25 0.075-0.4 5-22 130 33.5
1830×7000 24 25 ≤25 0.074-0.4 7.5-17 210 36
2100×3600 22 14-15.2 ≤25 0.074-0.4 15-36 370 46.8
2200×5500 21 30 ≤25 0.074-0.4 10-22 210 48.5
2200×6500 21 31 ≤25 0.074-0.4 14-26 380 52.8
2200×7500 21 33 ≤25 0.075-0.4 16-29 380 56
2400×3000 20.6 15.5-16.6 ≤25 0.074-0.4 22-44 245 59
2400×4500 21 30 ≤25 0.074-0.4 8.5-60 380 65

Product Pictures Show:

2 Tph Ball Mill Cement Ball Mill ,CE Approved 900*1800 Mill Price
