High Precision Durable Mineral Or Sand Washer Machine Quarry Equipment
High Precision Durable Mineral Or Sand Washer Machine Quarry Equipment
Specifications
Brand Name :
LIPU
Model Number :
XSL0765
Certification :
ISO9001:2008,CE,IQNet
Place of Origin :
Shanghai, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 sets/quarter
Delivery Time :
15-20 days after receiving advanced payment.
Packaging Details :
Export standard container or as customers' requirements.
Product Name :
Spiral Sand Washing Machine
Model :
XSL0765
Spiral diameter :
750 mm
Trough length :
6500 mm
Capacity :
20-50 t/h
Power :
5.5 kw
Overall dimension :
8380×1570×1920 mm
Weight :
4.3 t
Application :
Sand making industry
Color :
As customer's requirements
Condition :
New
Description

High Precision Durable Mineral Or Sand Washer Machine Quarry Equipment

Brief Introduction:

XSL series spiral sand washing machine can clean and separate sand stone and clay materials ,it is

kind of high strength mixing, washing and screening equipment , with the function such as cleaning and

dehydration.

Performance features:

1, Simple structure, stable operation, safe and reliable;

2, The fine sand is erosion rarely, the distribution and fineness modulus of washed building sand can

reach national standard.

3, Optimization design of the helical blade, making sure the spare parts to minimize loss.

Working Principle:

When the machine is working, the material goes into the input part. It will push the material to the

output through the machine. Surface dust and impurity are removed when the material from the

input part to the output part is pushed, mixed and washed. The final product goes out through the

discharge outlet and the mud and impurity will go out through overflow part.

Technical parameters:

Model

Spiral diameter

(mm)

Trough length

(mm)

Capacity

(t/h)

Power

(kW)

Overall dimension

L×W×H(mm)

Weight

(t)

XSL0550

500

5000

10-20

3

6540×1220×1630

2.5

XSL0765

750

6500

20-50

5.5

8380×1570×1920

4.3

XSL1075

1000

7500

50-80

7.5

9550×1920×2270

6.7

XSL1275

1200

7500

70-110

11

9700×2320×2660

10.8

XSL1585

1500

8500

90-130

18.5

11000×2830×3150

13.7

XSL1885

1800

8500

110-150

22

11100×3320×3620

15.4

XSL2085

2000

8500

130-170

22

11340×3670×3880

19

Note: No further notice if the technical parameters change .
