jaw crusher price advantages:
1. Big capacity and energy saving: no dead zone, feeding and crushing efficiency is greatly improved.
2. "V"-shape structure: the actual width of feed is the same as nominal width.
3. Good performance and good stability.
4. Lubrication system: safe, reliable and convenient, easy to maintenance.
5. Work long time: the internal structural precision greatly extend the life of equipment.
6. Adjustment device: increase the flexibility of the equipment.
7. Low noise and less dust.
8. Easy operation and maintenance, low operating costs.
Technical Data of JC Series Jaw Crusher:
| Model | Size of Feed Opening(mm) | Discharge Range(mm) | Capacity(t/h) | Motor Power(kw) | Weight (Excluding Motor)(kg) |
| JC231 | 510x800 | 40-150 | 50-250 | 55-75 | 9052 |
| JC340 | 600x1020 | 60-175 | 85-300 | 75-90 | 16460 |
| JC3540 | 650x1060 | 110-225 | 120-400 | 75-90 | 16872 |
| JC440 | 760x1020 | 70-200 | 120-520 | 90-110 | 27810 |
| JC443 | 850x1100 | 80-215 | 170-625 | 110-160 | 34722 |
| JC549 | 950x1250 | 110-250 | 260-810 | 132-160 | 50308 |
| JC5149 | 1100x1250 | 160-300 | 350-900 | 132-160 | 50550 |
| JC555 | 1070x1400 | 125-250 | 360-920 | 160-200 | 58907 |
| JC5155 | 1170x1400 | 225-350 | 600-1100 | 160-200 | 60162 |
| JC649 | 1100x1250 | 125-280 | 385-920 | 160-200 | 55954 |
| JC659 | 1200x1500 | 150-350 | 400-1200 | 200-250 | 90089 |
| JC663 | 1200x1600 | 150-350 | 500-1450 | 220-250 | 90789 |
| JC771 | 1500x1800 | 150-350 | 600-1800 | 315-400 | 124413 |
| JC983 | 1800x2100 | 175-350 | 700-2100 | 355-450 | 180000 |
