High Efficiency and Energy-saving PFQ1110 Model 150t/h 110kw Impact Crusher for Stone Yard and Mixing Station
High Efficiency and Energy-saving PFQ1110 Model 150t/h 110kw Impact Crusher for Stone Yard and Mixing Station
High Efficiency and Energy-saving PFQ1110 Model 150t/h 110kw Impact Crusher for Stone Yard and Mixing Station
High Efficiency and Energy-saving PFQ1110 Model 150t/h 110kw Impact Crusher for Stone Yard and Mixing Station
High Efficiency and Energy-saving PFQ1110 Model 150t/h 110kw Impact Crusher for Stone Yard and Mixing Station
High Efficiency and Energy-saving PFQ1110 Model 150t/h 110kw Impact Crusher for Stone Yard and Mixing Station
Specifications
Brand Name :
Aowei
Model Number :
PFQ1110
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5-10 Set/Month
Delivery Time :
5-7 days
Packaging Details :
Standard Package
Condition :
New
Processing Capacity :
80~150t/h
Max Feed Size :
400mm
Max Motor Power :
110kw
Motor type :
AC Motor
Warrenty :
1 Year
Applicable Fields :
Mainly used in sand and stone yard, mixing station, construction waste crushing and other fields
Applied Materials :
Limestone, dolomite, construction garbage, granite, basalt, river pebbles and so on
Description

Stone Crushing Machine Impact Rock Crusher Mining Crusher Machine

1.Description

Impact Crusher is a newly developed series impact crusher with high efficiency. It has smart structure and can be applied to primary crushing, secondary and fine crushing of a variety of materials with compression strength less than 250Mpa. Impact crusher can be widely used for mainly used in sand and stone yard, mixing station, construction waste crushing and other industries. Applicable materials: limestone, dolomite, construction garbage crushing, granite, basalt, river pebbles, etc.

2.Features

1. Tri-curtain cavity design.
2. Heavy duty rotor design.
3. Unique hammer locking device.
4. Replaceable liners.
5. Flexible application in primary and secondary crushing.

3.Working Principle

The PFQ series is a crushing machine that uses impact energy to break down materials. During operation, the motor drives the rotor to rotate at a high speed. When the material enters the action area of the hammer, it is broken by the high-speed impact of the hammer. The broken material is thrown in the tangential direction to the impact plate installed above the rotor to be broken again, and then The impact plate rebounds back to the hammer action zone and breaks again. This process is repeated until the material is broken to the desired particle size and is discharged from the discharge port. Adjusting the gap between the counter frame and the rotor can achieve the purpose of changing the material size and material shape.

4.Parameter

Model Max. Feed Size(mm) Discharge Size
(mm)		 Capacity
(t/h)		 Power
(kw)
<150MPa <250MPa
PFQ1108 300 150 30 50~100 75
PFQ1110 400 200 30 80~150 110
PFQ1310 500 200 40 140~200 160
PFQ1313 500 250 40 180~260 200
PFQ1315 600 300 40 200~300 250
PFQ1320 600 300 40 300~400 2×160
PFQ1520 800 400 40 350~550 2×250
PFQ1823 1000 500 40 550~850 2×400
PFQ2223 1200 600 40 850~1200 2×560
