Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Robust design 400t/h Granite Impact Crusher Machine
Specifications
Brand Name :
Aowei
Model Number :
PFQ1320
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 SET
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5-10 Set/Month
Delivery Time :
5-7 days
Packaging Details :
Standard Package
Condition :
New
Processing Capacity :
300~400t/h
Max Feed Size :
600mm
Max Motor Power :
2*160kw
Motor type :
AC Motor
Warrenty :
1 Year
Applicable Fields :
Mainly used in sand and stone yard, mixing station, construction waste crushing and other fields
Applied Materials :
Limestone, dolomite, construction garbage, granite, basalt, river pebbles and so on
Description

Stone Crushing Machine Coal Crusher Machine Granite Impact Crusher Machine

1.Description

Impact Crusher is a newly developed series impact crusher with high efficiency. It has smart structure and can be applied to primary crushing, secondary and fine crushing of a variety of materials with compression strength less than 250Mpa. Impact crusher can be widely used for mainly used in sand and stone yard, mixing station, construction waste crushing and other industries. Applicable materials: limestone, dolomite, construction garbage crushing, granite, basalt, river pebbles, etc

2.Benefits at a glance

  • Excellent crushing performance
  • Robust design
  • Quick and simple blow bar replacement
  • Large feed opening
  • Largely standardized and interchangeable wear parts
  • Low maintenance requirements

3.Working Principle

The electrical motor drives through V-belts and makes the rotor run at high speed. Materials will be fed into the crushing chamber from feed inlet, and be struck by the plate hammer which rotates at high speed. The materials are thrown up to the dentate reaction plate on the top of the crushing chamber and then falls down, the thrown-up and falling-down materials are crushed by striking with each other. The big incompletely crushed materials will form big stress and bending force at the interaction of hammer and thick impact plate in P crushing chamber, even the hard crushed materials will be broken and enter into the following S and T crushing chamber. The materials in these two crushing chambers can be medium and fine crushed by striking, impacting, bending and extruding, then discharged out of the machine.

4.Parameter

Model Max. Feed Size(mm) Discharge Size
(mm)		 Capacity
(t/h)		 Power
(kw)
<150MPa <250MPa
PFQ1108 300 150 30 50~100 75
PFQ1110 400 200 30 80~150 110
PFQ1310 500 200 40 140~200 160
PFQ1313 500 250 40 180~260 200
PFQ1315 600 300 40 200~300 250
PFQ1320 600 300 40 300~400 2×160
PFQ1520 800 400 40 350~550 2×250
PFQ1823 1000 500 40 550~850 2×400
PFQ2223 1200 600 40 850~1200 2×560
