HZS90 Concrete Batching Plant Manufacturers
HZS90 Concrete Batching Plant Manufacturers
HZS90 Concrete Batching Plant Manufacturers
HZS90 Concrete Batching Plant Manufacturers
Specifications
Brand Name :
MITNIK
Model Number :
HZS90
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1SET
Price :
negotiation
Supply Ability :
unlimited
Delivery Time :
15-20 days
Packaging Details :
Standard export packing
Description

HZS series concrete batching plant belongs to compulsory and efficiency equipment.It adopts the world popular quick installation modular structure, efficient imported concrete mixer,computerized controlled system and environment friendly design. This series of concrete batching plant is mainly used for projects like bridge, water conservancy, airport, dock and premixed concrete product factories where large quantity of concrete is needed.

HZS90 Concrete Batching Plant Manufacturers

Our concrete batching plant has the following characteristics:

1) It is low cost, adopts module-based structure and it is very convenient to install and move the whole machine.

a) The main machine is a compulsory dual-axial mixer,which has good mixing quality and high efficiency.

b) The aggregate is proportioned by the proportioning machine which is very accurate and fast.

c) The proportioning of the cement, water, liquid additive is done by electronic scale which is with high accuracy.

d) The water supply system adopts the siphon pump pressure principle, which increases the water speed and sprays evenly.

e) Main components of the electrical control system are all imported, which are with reliable performance, easy to operate, and could be printed.

2) It is very convenient to install and disassemble the whole production line. The sides of each storey of external packing can be opened and is easy to maintain and replace components.

Parematers of HZS concrete batching plant:

Item HZS25 HZS35 HZS50 HZS60 HZS75 HZS90 HZS100 HZS120
Capacity of Production(m3/h) ≥25 ≥35 ≥50 ≥60 ≥75 ≥90 ≥100 ≥120
Type of Mixer JS500 JS750 JS1000 JS1000 JS1500 JS1500 JS2000 JS2000
Volume of Storing Hopper(m3) 3*4 3*4 3*8 3*8 3*8 3*8 3*16 3*16
Max Aggregate Diameter(mm) 60/80 60/80 60/80 60/80 60/80 60/80 60/80 60/80
Discharg Height(m) 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8
Aggregate Measuring Accuracy(%) ±2 ±2 ±2 ±2 ±2 ±2 ±2 ±2
Cement Measuring Accuracy(%) ±1 ±1 ±1 ±1 ±1 ±1 ±1 ±1
Coal Ash Measuring Accuracy(%) ±1 ±1 ±1 ±1 ±1 ±1 ±1 ±1
Water Meassuring Accuracy(%) ±1 ±1 ±1 ±1 ±1 ±1 ±1 ±1
Addictive Measuring Accuracy(%) ±1 ±1 ±1 ±1 ±1 ±1 ±1 ±1
Total Power(kw) 55 83 138 145 160 196 190 250
Discharge Height(m) 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8
