IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine
IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine
IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine
IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine
Specifications
Brand Name :
JONE
Model Number :
MMA-315M
Certification :
CE
Place of Origin :
GUANGDONG,CHINA
MOQ :
100
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
70000+PCS+per /month
Delivery Time :
4 WEEKS
Packaging Details :
CARTON
Type :
MOS 3 PCB
AC Input Power Capacity(KVA) :
220V
Rated Input Power Capacity(KVA) :
9.2
Input Frequency(Hz) :
50/60
Non-load Voltage(V) :
56
Output current range(A) :
20-315
Rated Duty Cycle(%) :
60%
Efficiency(%) :
85%
Class of Insulation :
F
Protection class of case :
IP21
Electrode diameter(mm) :
1.6-5.0
Quick joint Size(mm) :
35-50
Input power cable(m) :
1.8
N.W./G.W.(kg) :
11/13
Accessories :
holder、clamp、mask、brush、manual
Usage :
Welding
Condition :
New
Machine Size(L*W*H) :
480*215*425MM
Warranty :
24Months
Description

IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine

Description

MMA welding machines are used to weld metal parts together. They are used in the automotive and aerospace industries, building construction, as well as other industrial applications.

MMA welding machines can be used to weld steel, aluminum, stainless steel, copper and alloys. They are versatile tools that can be adapted to many different processes requiring precise alignment of parts or multiple passes.

MMA welding machines are typically used for joining flat or curved surfaces where smooth finishes are required. Their high output allows for large repairs at a fraction of the cost of traditional methods such as spot welding.

IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine

technical parameter

Model MMA-250M MMA-280M MMA-315M
Type MOS 3PCB MOS 3PCB MOS 3PCB
AC Input Voltage(V) 220V (110V/220V can do) 220V (110V/220V can do) 220V (110V/220V can do)
Rated Input Power Capacity(KVA) 7 7.7 9.2
Input Frequency(Hz) 50/60 50/60 50/60
Non-load Voltage(V) 56 56 56
Output current range(A) 20-250 20-280 20-315
Rated Duty Cycle(%) 60% 60% 60%
Efficiency(%) 85% 85% 85%
Class of Insulation F F F
Protection class of case IP21 IP21 IP21
Electrode diameter (mm) 1.6-4.0 1.6-5.0 1.6-5.0
Quick joint Size(mm) 35-50 35-50 35-50
Input power cable(m) 1.8 1.8 1.8
N.W./G.W.(kg) 5.3/6.8 6/7.5 11/13
Machine Size(LxWxH mm) 420*160*310 420*160*310 480*215*380
Package(LxWxH mm) 455*270*355 kraft paper box 455*270*355 kraft paper box 540*295*425 kraft paper box
Accessories 1.8m 16mm2 200A holder 1.8m 16mm2 200A holder 1.8m 25mm2 300A holder
1.2m 16mm2 300A clamp 1.2m 16mm2 300A clamp 1.2m 25mm2 300A clamp
Brush,Mask,Manual Brush,Mask,Manual Brush,Mask,Manual

IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine

IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine

IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine

IP21 Mosfet Inverter Dc Arc Welder 220V MMA 315 Welding Machine
