Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
Specifications
Brand Name :
JONE
Model Number :
MIG/MMA-350F 500F
Certification :
CE、ISO9001
Place of Origin :
GUANGDONG,CHINA
MOQ :
10
Price :
Negotiate
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
1000 pieces per year
Delivery Time :
30 days
Packaging Details :
kraft paper box with foam
Type :
IGBT MODULE
AC Input Power Capacity(KVA) :
380V
Input Frequency(Hz) :
50/60
Non-load Voltage(V) :
54
Output current range(A) :
50-350A
Welding-wire diameter (mm) :
0.8, 1.0, 1.2
Rated Duty Cycle(%) :
35℃/40%
Efficiency(%) :
93%
Quick joint Size(mm) :
50-70
Type of the wire feeder :
DC24V-350A
Machine Size(LxWxH mm) :
580*330*600
Package Dimension(LxWxH mm) :
670*330*585
Description

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

MIG welding, also known as wire-feed welder and MIG (Metal Inert Gas), is a type of arc welding. This process uses a wire feed to feed solid filler wire to the weld joint. The wire feed is connected to a constant voltage power supply that creates the arc to melt the wire when it hits the weld joint. Before the wire creates an arc there needs to be a shielding gas feed through the system.

MIG welding is a very popular process of joining metals. The name is often shortened to simply "MIG". It's commonly known as "Wire Wheel Welding", but really this name describes the process that happens before the trigger hits the wire. Wire feed is connected to a constant voltage power supply that creates an arc to melt the wire when it hits the weld joint. Before that happens there needs to be a shielding gas feed through the system.

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High PerformanceMig-350 3P Industrial Inverter Co2 Mig Welder Machine High PerformanceMig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

technical parameter

Model MIG/MMA-350F MIG/MMA-500F
Type of the wire feeder IGBT MODILE 15KG MIG WIRE IGBT MODILE 15KG MIG WIRE
Real Amp(A) 350 500
AC input Voltage(V) AC 380V AC 380V
Rated Input Power Capacity(KVA) 14 25
Input Frequency(Hz) 50/60 50/60
Non-load Voltage(V) 54V 56V
Output current range(A) 50-350A 50-500A
Welding-wire diameter (mm) 0.8, 1.0, 1.2 0.8,1.0, 1.2,1.6
Rated Duty Cycle(%) 35℃/40% 35℃/60%
Efficiency(%) 93% 93%
Class of Insulation F F
Protection class of case IP21S IP21S
Quick joint Size(mm) 50-70 50-70
Type of the wire feeder DC24V-350A DC24V-500A
Wire-feeding speed (m/min) 3.6--12 3.6--20
Post flow time (S) 0.5 0.5
N.W./G.W.(kg) 25/29 32/36
Machine Size(LxWxH mm) 580*330*600 650*330*630
Package Dimension(LxWxH mm) 670*330*585 kraft paper box+foam 765*425*680mm kraft paper box+foam

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance

Mig-350 3P Industrial Inverter Co2 Mig Welder Machine High Performance
