Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine
Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine
Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine
Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine
Specifications
Brand Name :
JONE
Model Number :
MIG/MMA/TIG-270D
Certification :
CE
Place of Origin :
GUANGDONG,CHINA
MOQ :
100
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
70000 PCS+per /month
Delivery Time :
4 WEEKS
Packaging Details :
CARTON
Type :
IGBT <5KG ,Gas/Gasless
AC Input Power Capacity(KVA) :
220V
Rated Input Power Capacity(KVA) :
6
Input Frequency(Hz) :
50/60
Non-load Voltage(V) :
52
Output current range(A) :
20-270
Rated Duty Cycle(%) :
60%
Efficiency(%) :
85%
Class of Insulation :
F
Protection class of case :
IP21
Quick joint Size(mm) :
35-50
Input power cable(m) :
1.8
N.W./G.W.(kg) :
8.8/11.8KG
Accessories :
holder、clamp、3M 15AK Torch、 mask、brush、manual
Usage :
Welding
Condition :
New
Machine Size(L*W*H) :
460*185*330MM
Warranty :
24Months
Description

Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine

MIG welding has been around for almost a century. Invented in 1915, it is the most popular process used to weld together metal parts. The process uses electricity and an inert filler gas to create an arc that melts the material at the joint so it can be welded together. MIG welding is also called wire wheel welding because of the way wire is fed into the weld joint using a wire feed. The wire feeder has a trigger that when squeezed starts the welding process. The electrodes are held by grips, which are made of tungsten carbide or imbedded graphite rods, each channeled down one side of the handle to keep them cool while they are being used.

MIG welding is an easy and simple process that makes working with metal a breeze. The wire feed makes sure there is a solid weld joint every time and the shielding gas protects your work piece from any harsh environment. This can be used to create parts in a variety of materials and finishes, including stainless steel.



Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine

technical parameter

Model MIG/MMA/TIG-270D
Type IGBT, ≤ 5kg, Gas/Gasless type
AC Input Voltage(V) 220V(110V/220V can do)
Rated Input Power Capacity(KVA) 6
Input Frequency(Hz) 50/60
Non-load Voltage(V) 52
Output current range(A) 20-270
Rated Duty Cycle(%) 60%
Efficiency(%) 85%
Class of Insulation F
Protection class of case IP21
Wire diameter(mm) 0.8/1.0
Wire weight(kg) ≤ 5kg
Quick joint Size(mm) 35-50
Input power cable(m) 1.8
N.W./G.W.(kg) 8.8/11.8
Machine Size(LxWxH mm) 460*185*330
Package(LxWxH mm)/ 8 in 1 535*265*370 kraft paper box+ foam
Accessories 1.8M 16mm2 200A holder
1.2M 16mm2 300A clamp
3m 15AK Torch
Brush, Mask, Manual






Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine

Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine


Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine
Mig-270D Industrial MIG Welder single phase IP21 No Gas Mig Welding Machine
