AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
Specifications
Brand Name :
JONE
Model Number :
MIG/MMA-350F 500F
Certification :
CE、ISO9001
Place of Origin :
GUANGDONG,CHINA
MOQ :
10
Price :
Negotiate
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
1000 pieces per year
Delivery Time :
30 days
Packaging Details :
kraft paper box with foam
Type :
IGBT MODULE
AC Input Power Capacity(KVA) :
380V
Input Frequency(Hz) :
50/60
Non-load Voltage(V) :
54
Output current range(A) :
50-350A
Welding-wire diameter (mm) :
0.8, 1.0, 1.2
Rated Duty Cycle(%) :
35℃/40%
Efficiency(%) :
93%
Quick joint Size(mm) :
50-70
Type of the wire feeder :
DC24V-350A
Machine Size(LxWxH mm) :
580*330*600
Package Dimension(LxWxH mm) :
670*330*585
Description

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

MIG welding stands for "Metal Inert Gas" and was originally the only form of welding used on many projects. The process uses a wire feed to feed solid filler wire to the weld joint. The wire feed is connected to a constant voltage power supply that creates a spark that melts the wire when it hits the weld Joint, then it forms an arc between them. Before the wire creates an arc there needs to be a shielding gas feed through the system. MIG welding is done through a MIG gun that combines the wire, electricity and shielding gasses all at the same time.

MIG welding, or MIG, is a weld process that combines power and shielding gases into one simple machine. You can weld with MIG either on a shielded or open (open arc) torch. This process uses a wire feed to feed solid filler wire to the weld joint. The wire feed is connected to a constant voltage power supply that creates the arc to melt the wire when it hits the weld joint. Before the wire creates an arc there needs to be a shielding gas feed through the system.

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding MachineAC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding MachineAC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

technical parameter

Model MIG/MMA-350F MIG/MMA-500F
Type of the wire feeder IGBT MODILE 15KG MIG WIRE IGBT MODILE 15KG MIG WIRE
Real Amp(A) 350 500
AC input Voltage(V) AC 380V AC 380V
Rated Input Power Capacity(KVA) 14 25
Input Frequency(Hz) 50/60 50/60
Non-load Voltage(V) 54V 56V
Output current range(A) 50-350A 50-500A
Welding-wire diameter (mm) 0.8, 1.0, 1.2 0.8,1.0, 1.2,1.6
Rated Duty Cycle(%) 35℃/40% 35℃/60%
Efficiency(%) 93% 93%
Class of Insulation F F
Protection class of case IP21S IP21S
Quick joint Size(mm) 50-70 50-70
Type of the wire feeder DC24V-350A DC24V-500A
Wire-feeding speed (m/min) 3.6--12 3.6--20
Post flow time (S) 0.5 0.5
N.W./G.W.(kg) 25/29 32/36
Machine Size(LxWxH mm) 580*330*600 650*330*630
Package Dimension(LxWxH mm) 670*330*585 kraft paper box+foam 765*425*680mm kraft paper box+foam

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine

AC380V CO2 Gasless Flux Argon Mig Welder 350 Amp Welding Machine
