Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
Specifications
Brand Name :
JN
Model Number :
Customize
Certification :
CE ISO
Place of Origin :
Hebei, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
50 Sets per month
Delivery Time :
about 20 days
Packaging Details :
Seaworthy Packing
Material Thickness :
0.3-0.8mm
Yield Strength :
235MPa 345MPa And 550MPa.
Automatic: :
PLC controlled, full automatic
Material :
PPGI,Color Steel,GI
Rolling shaft material :
45 # Steel
Usage :
Roof sheet
Description

Adjustable Speed Double Layer Metal Roofing Sheet Using 45 # Steel

Description & Application:

This type of sheet can be widely used in plant, house, storage and simple steel roof and wall. It has advantage of pretty appearance, durable using and so on.

Glazed tile, Roof Tile, Metal roof tile; steel roof tile; color steel tile; color glazed tile; wave tile; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Work Flowing:

Decoiler --- Fedding Guide --- Film Covering --- Roll Forming --- Pressing --- Cut-to-length --- Run out table

Specification / Technical Parameter

No. Main parameter of Metal Roof Sheet Roll Forming Machine
1 Suitable to process Color steel plate
2 Width of the plate 1200mm
3 Rollers 14 rows
4 Dimensions 7100*1550*1510mm
5 Power 4+4kw
6 Rolling material 45# steel(plated chrome on surface)
6 Thickness of the plate 0.3-0.6mm
7 Productivity 8-10m/min
8 Diameter of the roller Φ70mm
9 Voltage 380V 50Hz 3phases
10 Material of the cutting plate Cr12
11 Hydraulic 40#
12 Processing precision Within 1.00mm
13 Control system PLC control

Feature & Advantages:

Adjustable Speed Double Layer Metal Roofing Sheet Using 45 # Steel

1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong

2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.

3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.

4. High precision: shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.

5 .automatic PLC : introduced Mitsubishi PLC with touch screen ,inverter,transformer.

6. powerful driving system: big inch train,or gear box driving system.

6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.

Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall

Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall

Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall

Adjustable Speed Double Layer Metal Roofing Machine For Steel Roof And Wall
