Specifications
Brand Name :
JN
Model Number :
Customize
Certification :
CE ISO
Place of Origin :
Hebei, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
50 Sets per month
Delivery Time :
about 20 days
Packaging Details :
Seaworthy Packing
Material Thickness :
0.3-0.8mm
Working speed :
15m/min
Automatic: :
Auto PLC Control Hydraulic
Cutting Blade Material :
Cr12
Roller Material :
No.45steel
Usage :
Road Structural Highway Guardrail
Description

Road Structural Highway Guardrail Roll Forming Machine For Traffic Barrier

Description:

Highway guardrails have proven highly effective in reducing the frequency and severity of accidents. A recent Transportation Research Board study determined that guardrails are at least 97% effective in reducing injuries & fatalities. Since their inception during the 1960s, W-beam guardrails have protected millions of travelers by containing or deflecting run-off-road vehicles from impact with roadside hazards.

Machine composition

Road Structural Highway Guardrail Roll Forming Machine For Traffic Barrier Main Components
No. Name Unit Qty
1 Decoiler set 1
2 Main Machine for roll forming set 1
3 Control System(PLC) set 1
4. Hydraulic oil pump set 1
5. Product stand set 1
Remark: Decoiler have manual decoiler,Electric decoiler and Hydraulic decoiler,can booking as request

Working Flow of Machine

Decoiler--- Feeding---- Roll Forming ---- Cutting ---- output

Technical Parameter of Highway Guardrail Roll Forming Machine:

Length of the main part About15500*1650*1500mm
Weight of main part About 9.5 ton
Voltage 380V/50HZ3Phase (as customer`s request)
Roller fixer Middle plate welded
Frame 400H steel welded
Middle plate thickness 30mm
Drive mode Chain Drice//Gear Drive
Material of rollers GCR15, quenched treated HRC58-62℃
Material of shafts 45# steel
Diameter of shafts Φ90mm(depend on defferent design)
Number of rollers: 16 rollers
Main power 37kw
Cutting&Hydraulic Double guide pillar
Hydraulic motor power 15kw
Hydraulic Pressure 10-12MPa
Cutting drive Decelerating motor + Chain drive gear all by high-frequency
Control System PLC system: Mitstubishi, Panasonic,Detal,Siemens,Schneider
Feeding Material width Better as your drawing or from our designer
Feeding Thickness 3~4mm
Effective width Better as your drawing or from our designer
Productivity 15m/min

Features and Advantages:

Road Structural Highway Guardrail Roll Forming Machine For Traffic Barrier

♥ Repair parts are off the shelf - making them inexpensive and easily accessible

♥ Cepair parts are off the shelf - making them inexpensive and easily accessible

♥ Allows for radius as low as 355 m

♥ Only 19 inches wide making it ideal for narrow median in construction zones

♥ Low deflection, "fully pinned" option available

Packaging Detail of stud and track roll forming machine :

1. One 40ft container for loading one set machine with manual decoiler;
2. The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.
