Android 9.0 Vehicle Mount Shockproof Terminal Real Time GPS Tracking
Android 9.0 Vehicle Mount Shockproof Terminal Real Time GPS Tracking
Android 9.0 Vehicle Mount Shockproof Terminal Real Time GPS Tracking
Android 9.0 Vehicle Mount Shockproof Terminal Real Time GPS Tracking
Specifications
Brand Name :
UniStrong
Model Number :
E9638-A7
Place of Origin :
China
MOQ :
5
Payment Terms :
T/T
Supply Ability :
20000
Delivery Time :
THD
Packaging Details :
GIFTBOX PACKAGE
Item name :
Android Quad-core Vehicle Intelligent Display Terminal
support two protocols :
SAEJ1939 Protocol ISO15765 Protocol
The full functional :
Professionally solving fleet management problems in various automotive industries to meet all your needs.
Certification :
3C, ROHS
CAN interfaceperature :
-20℃~+70℃ humility:0%~90%RH"
Storage temperature :
-30℃ ~ 80℃
Description

Taxi/Bus/Truck Real Time GPS Tracking, Dispatch and Management System of E9638A

Product application

1. The new generation of E9638-A rugged vehicle terminal is specially designed for efficient logistics applications, with excellent economical and durable performance.

2. Impact-resistant and wear-resistant multi-touch capacitive screen, and excellent WIFI roaming. Built for extreme industrial environments.
3.The E9638-A mobile data terminal provides vehicle monitoring and fleet management application solutions to assist fleet owners to track truck movement resources and manage truck scheduling more effectively.

Product feature:

1. 7 inch touch screen Support WLAN/LTE/Bluetooth, support seamless WiFi roaming

2. 5M3 shockproof and shockproof certification

3. Passed CE, Emark certification

Product appearance
Type Detail Standard configuration
IP rate waterproof IP65
LCD dimension 7",1024*600
TP touch panel Support 5 points capacitive screen,G+G
Speaker built in 4Ω/2W
super capacitor built in 5.4V/10F
Hardware Configuration
Type Detail Standard configuration
CPU model Qualcomm SDM450,Octa-core ARM Cortex-A53 64-bit CPU @ 1.8 GHz
RAM DDR3 2GB
ROM EMMC 16GB
Sensor Accelerometer Triaxial accelerometer
Wireless communication
Type Detail Standard configuration
WIFI WIFI module 2.4G+5G WiFi,IEEE802.11 g/b/n /ac
Bluetooth built in BT2.1+EDR/3.0/4.1/4.2 BLE
GNSS built in GPS+BD module
3G/4G built in Module:SC60CEYB-16GB-UGAD cat6 (LTE 4G CHINA)
LTE FDD :B1/B3/B5/B8
LTE TDD:B34/B38/B39/B40/B41
TD-SCDMA:B34/B39
WCDMA :B1/B8
CDMA2000/EVDO:BC0
GSM:900/1800MHz
M1,M2,M3 port function extension
Type Detail Standard configuration
M1 PORT(12pin) Extend RS232 UART*2
DC11V output 500mA*3
Input IO(9-36V)*1
RS485*1
M2 PORT(10pin) Extend CAN *2
1*input IO(2-36V)*1
power input ,B+,B- ,ACC (9-36V)
M3 PORT(8pin) Extend USB-HOST*1
Camera*2
Interfaces
Type Detail Standard configuration
USB device USB Micro-USB *1
USB HOST USB HOST USB type-A *1
Double SIM Card 3G/4G SIM card Standard SIM card interface*1 + E-SIM *1
TF Card TF support SDHC*1 max:128GB
GNSS Fakra Fakra C head *1
4G Fakra Fakra D head *1
M1,M2,M3 port Extend 12pin/10pin/8pin
button button power button*1, Function buttons*2
Accessory
Type Detail Standard configuration
M1 cable full function E9638_12pin full functional cable
M2 cable full function E9638_10pin full functional cable
M3 cable full function E9638_8pin full functional cable
GNSS antenna external 1575.42±1.023MHZ 1602±8MHZ, DC current:10mA,FAKRA C head；80cm length
LTE antenna external 4G LTE,central frequency 824MHz~960MHz,1710MHz~2200MHz,2300MHz~2700MHz；FAKRA D head,80cm length
Camera Optional Optional 1080P AHD camera
Software Configuration
Type Detail Standard configuration
OS version Android 9.0
Reliability
Type Detail Standard configuration
Working environment Working temp -20℃~+70℃ humidity:0%~90%RH
Storage temp -30 °C to 80 °C
vibration ISO16750 / MIL-STD-810G
Certification Domestic 3C, ROHS

Service
1.Standard free 1 year warranty for the product;
2. Sample test and debug support;
3. ODM/Customized requirements assessment and quotation;
4. Product ID design ;

FAQ
1. Question: How to contact you for detail information?
Answer: You can contact us through "Contact" button. Or you can write email to us at: mk.hu@unistrong.com

2. Question: Are you manufacture?
Answer: Yes, we are the original manufacture. We have 50-person R&D team to support various customer’s demands.

3. Question: Will the sample provide software SDK?
Answer: Yes, we will support software debug according to your demands and requirements.

4. How fast you could make the delivery?
Answer: 2 weeks for standard configuration; And if the product are customized, the delivery date will be longer according to materials status.
