E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch
E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch
E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch
E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch
E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch
E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch
Specifications
Brand Name :
UniStrong
Model Number :
E9638-A9
Place of Origin :
China
MOQ :
5
Payment Terms :
T/T
Supply Ability :
20000
Delivery Time :
THD
Packaging Details :
GIFTBOX PACKAGE
CPU :
Qualcomm SDM450,Octa-core ARM Cortex-A53 64-bit CPU @ 1.8 GHz
Bluetooth :
BT2.1+EDR/3.0/4.1/4.2 BLE
Sensor :
Triaxial accelerometer
IP rate :
IP65
positioning :
2.5M accurate positioning
WIFI module :
2.4G+5G WiFi,IEEE802.11 g/b/n /ac
Description

E9638K support Hand microphone voice intercom, which can be used on vehicle on Mine vehicle dispatch

Product application
1. 1. Impact-resistant and wear-resistant multi-touch capacitive screen, and excellent WIFI roaming. Built for extreme industrial environments.
2.The E9638-A vehicle monitoring system is specially developed for fleet management. Its mobile data terminal and heat dissipation solution adopt seismic design to meet all the requirements of transport vehicles. You can obtain accurate data through mobile data terminals.
3.Unistrong also provides customized services to meet customers' diverse automotive computer integration needs.

Product feature:

1.Wide temperature operation of the whole machine (-30 ~ 50 °C/-22 ~ 122 °F)
2.Capacitive multi-touch screen with wear and scratch verification can withstand physical pressure.
3. 5M3 shockproof and shockproof certification

Product appearance
TypeDetailStandard configuration
IP ratewaterproofIP65
LCDdimension7",1024*600
TPtouch panelSupport 5 points capacitive screen,G+G
Speakerbuilt in4Ω/2W
super capacitorbuilt in5.4V/10F
Hardware Configuration
TypeDetailStandard configuration
CPUmodelQualcomm SDM450,Octa-core ARM Cortex-A53 64-bit CPU @ 1.8 GHz
RAMDDR32GB
ROMEMMC16GB
SensorAccelerometerTriaxial accelerometer
Wireless communication
TypeDetailStandard configuration
WIFIWIFI module2.4G+5G WiFi,IEEE802.11 g/b/n /ac
Bluetoothbuilt inBT2.1+EDR/3.0/4.1/4.2 BLE
GNSSbuilt inGPS+BD module
3G/4Gbuilt inModule:SC60CEYB-16GB-UGAD cat6 (LTE 4G CHINA)
LTE FDD :B1/B3/B5/B8
LTE TDD:B34/B38/B39/B40/B41
TD-SCDMA:B34/B39
WCDMA :B1/B8
CDMA2000/EVDO:BC0
GSM:900/1800MHz
M1,M2,M3 port function extension
TypeDetailStandard configuration
M1 PORT(12pin)ExtendRS232 UART*2
DC11V output 500mA*3
Input IO(9-36V)*1
RS485*1
M2 PORT(10pin)ExtendCAN *2
1*input IO(2-36V)*1
power input ,B+,B- ,ACC (9-36V)
M3 PORT(8pin)ExtendUSB-HOST*1
Camera*2
Interfaces
TypeDetailStandard configuration
USB deviceUSBMicro-USB *1
USB HOSTUSB HOSTUSB type-A *1
Double SIM Card3G/4G SIM cardStandard SIM card interface*1 + E-SIM *1
TF CardTFsupport SDHC*1 max:128GB
GNSSFakraFakra C head *1
4GFakraFakra D head *1
M1,M2,M3 portExtend12pin/10pin/8pin
buttonbuttonpower button*1, Function buttons*2
Accessory
TypeDetailStandard configuration
M1 cablefull functionE9638_12pin full functional cable
M2 cablefull functionE9638_10pin full functional cable
M3 cablefull functionE9638_8pin full functional cable
GNSS antennaexternal1575.42±1.023MHZ 1602±8MHZ, DC current:10mA,FAKRA C head；80cm length
LTE antennaexternal4G LTE,central frequency 824MHz~960MHz,1710MHz~2200MHz,2300MHz~2700MHz；FAKRA D head,80cm length
CameraOptionalOptional 1080P AHD camera
Software Configuration
TypeDetailStandard configuration
OSversionAndroid 9.0
Reliability
TypeDetailStandard configuration
Working environmentWorking temp-20℃~+70℃ humidity:0%~90%RH
Storage temp-30 °C to 80 °C
vibrationISO16750 / MIL-STD-810G
CertificationDomestic3C, ROHS
