RAM Mounted IP65 Android Tablet 824MHz - 960MHz With Super Capacitor
RAM Mounted IP65 Android Tablet 824MHz - 960MHz With Super Capacitor
RAM Mounted IP65 Android Tablet 824MHz - 960MHz With Super Capacitor
RAM Mounted IP65 Android Tablet 824MHz - 960MHz With Super Capacitor
Specifications
Brand Name :
UniStrong
Model Number :
E9638-A24
Place of Origin :
China
MOQ :
5
Payment Terms :
T/T
Supply Ability :
20000
Delivery Time :
THD
Packaging Details :
GIFTBOX PACKAGE
positioning :
2.5M accurate positioning
Sensor :
Triaxial accelerometer
IP rate :
IP65
Item name :
Android Quad-core Vehicle Intelligent Display Terminal
WIFI module :
2.4G+5G WiFi,IEEE802.11 g/b/n /ac
Description

E9638A with Super capacitor, power-off protection, RAM mounted, good after-sales service

Product application
1. E9638-A can highly meet the application requirements of fleet management. It can withstand vibration, dust and water, and supports a wide operating temperature, making it very suitable for extreme vehicle environments.
2. The E9638-A mobile data terminal provides vehicle monitoring and fleet management application solutions to assist fleet owners to track truck movement resources and manage truck scheduling more effectively.

Product feature:

1. 5m drop test for reliability test (MIL-STD-810G/Method516.6/Procedure IV & Touch Panel IK05)

2. Low-profile and diverse Wi-Fi antennas are specially designed for logistics, matching the environmental conditions. bug fixes, system patches, and additional features.

3. Passed CE, Emark certification

Product appearance
TypeDetailStandard configuration
IP ratewaterproofIP65
LCDdimension7",1024*600
TPtouch panelSupport 5 points capacitive screen,G+G
Speakerbuilt in4Ω/2W
super capacitorbuilt in5.4V/10F
Hardware Configuration
TypeDetailStandard configuration
CPUmodelQualcomm SDM450,Octa-core ARM Cortex-A53 64-bit CPU @ 1.8 GHz
RAMDDR32GB
ROMEMMC16GB
SensorAccelerometerTriaxial accelerometer
Wireless communication
TypeDetailStandard configuration
WIFIWIFI module2.4G+5G WiFi,IEEE802.11 g/b/n /ac
Bluetoothbuilt inBT2.1+EDR/3.0/4.1/4.2 BLE
GNSSbuilt inGPS+BD module
3G/4Gbuilt inModule:SC60CEYB-16GB-UGAD cat6 (LTE 4G CHINA)
LTE FDD :B1/B3/B5/B8
LTE TDD:B34/B38/B39/B40/B41
TD-SCDMA:B34/B39
WCDMA :B1/B8
CDMA2000/EVDO:BC0
GSM:900/1800MHz
M1,M2,M3 port function extension
TypeDetailStandard configuration
M1 PORT(12pin)ExtendRS232 UART*2
DC11V output 500mA*3
Input IO(9-36V)*1
RS485*1
M2 PORT(10pin)ExtendCAN *2
1*input IO(2-36V)*1
power input ,B+,B- ,ACC (9-36V)
M3 PORT(8pin)ExtendUSB-HOST*1
Camera*2
Interfaces
TypeDetailStandard configuration
USB deviceUSBMicro-USB *1
USB HOSTUSB HOSTUSB type-A *1
Double SIM Card3G/4G SIM cardStandard SIM card interface*1 + E-SIM *1
TF CardTFsupport SDHC*1 max:128GB
GNSSFakraFakra C head *1
4GFakraFakra D head *1
M1,M2,M3 portExtend12pin/10pin/8pin
buttonbuttonpower button*1, Function buttons*2
Accessory
TypeDetailStandard configuration
M1 cablefull functionE9638_12pin full functional cable
M2 cablefull functionE9638_10pin full functional cable
M3 cablefull functionE9638_8pin full functional cable
GNSS antennaexternal1575.42±1.023MHZ 1602±8MHZ, DC current:10mA,FAKRA C head；80cm length
LTE antennaexternal4G LTE,central frequency 824MHz~960MHz,1710MHz~2200MHz,2300MHz~2700MHz；FAKRA D head,80cm length
CameraOptionalOptional 1080P AHD camera
Software Configuration
TypeDetailStandard configuration
OSversionAndroid 9.0
Reliability
TypeDetailStandard configuration
Working environmentWorking temp-20℃~+70℃ humidity:0%~90%RH
Storage temp-30 °C to 80 °C
vibrationISO16750 / MIL-STD-810G
CertificationDomestic3C, ROHS

Service
1.Standard free 1 year warranty for the product;
2. Sample test and debug support;
3. ODM/Customized requirements assessment and quotation;
4. Product ID design ;
