2.4 Inch Transflective TFT LCD Cell Phone Touch Screen / Mobile LCD Replacement
2.4 Inch Transflective TFT LCD Cell Phone Touch Screen / Mobile LCD Replacement
2.4 Inch Transflective TFT LCD Cell Phone Touch Screen / Mobile LCD Replacement
2.4 Inch Transflective TFT LCD Cell Phone Touch Screen / Mobile LCD Replacement
Specifications
Brand Name :
SWT
Model Number :
TN20320008F
Certification :
CE
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000pcs/week
Delivery Time :
1-3days
Packaging Details :
by carton
Touch Screen Type :
Surface Acoustic Wave
Usage :
Small-sized LCM
Response Time :
3ms
Model NO :
TN20320008F
LCD Drive Mode :
Static Drive LCD Module
Specification :
CE FCC ROHS
Description

2.4 Inch Transflective TFT LCD Mobile Phone Touch Screen , Small-sized LCM​


General Specifications:

Item Standard Value
Size 2.4
Display Format 240(RGB) *320
LCD Type TFT , Transflective , Positive

Viewing Direction(Gray Inversion)		 12 O'clock
polaroid Up: 0.17mm,Down,:0.17mm
Backlight White LED
Interface RGB/MCU
Driver IC Driver IC : ILI9341V

BIGBOOK TFT LCD Module Series:
1. Our standard TFT LCD Module size:
1.44'', 1.77", 2.0", 2.4", 2.8", 3.2", 3.5",
4"(3.97"), 4.3", 5", 7", 8", 9'', 10.1".
2. Developed 4.0''(3.97'') LCD module with IPS glass.
3. Developed 2.4'' to 7.0'' TFT LCD with ZIF FPC connection.
4. Standard CTP for 3.2'', 3.5'', 4.3", 5.0", 7'', 8'', 10.1''.
5. High transmittance RTP for 4.3" and 7".
6. Can make customized CTP.2.4 Inch Transflective TFT LCD Cell Phone Touch Screen / Mobile LCD Replacement

Mechanical Specifications:

Item Standard Value Unit
Outline Dimension 42.72 (W) * 59.26 (L) * 2.5 (H)+-0.05 mm
Active Area 36.72 (W) * 48.96 (L) mm
Dot Size 0.153 (W) * 0.153 (L) mm

Our Services:
1. Free repair within one year after the shipment of products from us.
2. Replacement within 30 days after the shipment of products from us due to products' problems.
3. We can print your logo and stick your model No.on the cameras.
4. We have long cooperation with many shipping companies and our export volume is large. The shipping companies
can offer us good discounts.
5. Professional technician supports. We have a good after-sales service team. They can solve your problems in time.
